GRANIT Z50 Control Valve 87000920 | 1 DA | 40 l/min | 250 bar

GRANIT Z50 Monoblock Hydraulic Control Valve | 1x Double Acting | 40 l/min | 250 bar

Granit
87000920

GRANIT 1 Lever 40 Liter Hydraulic Distributor 87000920

Hurry! only 3 items left in stock.
€64.90
Tax included
Quantity

Ready for delivery
Add to Compare
Add to Wishlist
  Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

  Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

  Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

The GRANIT 87000920 hydraulic distributor is a 4/3 way monoblock directional valve with a single lever, designed to control a double-acting cylinder. The specific spool function features A-B ports closed and the lever returning to the neutral (center) position actuated by a spring. Made of cast iron, it is ideal for hydraulic systems requiring a nominal pressure of 250 bar and a maximum flow rate of 40 l/min.

Functional and Hydraulic Specifications

  • Version: 4/3 way, 1 x double acting (A-B closed / spring return).
  • Lever Function: 1 x double acting.
  • Flow Rate (l/min): 40.
  • PN (Nominal Pressure): 250 bar.
  • Adjustment Range (Maximum Pressure): 120-250 bar.
  • Nominal Operating Pressure P - N (Inlet-Outlet): 250 bar.
  • Nominal Operating Pressure A - B (Working Ports): 300 bar.
  • Nominal Operating Pressure T (Tank): 50 bar.
  • Internal Leakage: approx. 15 cm³ /min at 120 bar.
  • Oil Temperature: -15° C to +80°C.
  • Contamination Level: 10 according to NAS1638.

Technical and Structural Data

  • Part Number: 87000920.
  • Orig. Ref.: 01Z50 A1 GKZ1.
  • Lever: 1.
  • Version: cast iron monoblock valve.
  • Connection P (Inlet, BSP): G 1/2".
  • Connection T (Tank, BSP): G 1/2".
  • Connection N (Inlet, BSP): 1/2" BSP.
  • Connection A-B (Working Ports, BSP): G 3/8".

Dimensions (mm)

Dimensional data for installation:

  • A: 60 mm.
  • B: 80 mm.
  • C: 85 mm.
  • D: 60 mm.
