GRANIT Reclining Seat (24000077)

Product Description

The GRANIT seat (product code 24000077) stands out for its automatic reclining function, making it ideal for specific applications where the seat needs to return to a compact position when not in use. The mechanical suspension with a double-acting shock absorber and weight adjustment guarantees a comfortable ride. Multiple adjustments, including longitudinal and five-step tilt adjustments, allow for optimal seating customization. The PVC upholstery ensures easy maintenance and durability.

Technical Specifications

• Product Code: 24000077
• Special Feature: The seat cushion automatically reclines when unloaded.
• Suspension: Mechanical, with double-acting shock absorber
• Adjustments:
  • Weight adjustment: 50 kg to 120 kg
  • Longitudinal adjustment: 150 mm (on tracks)
  • Tilt adjustment: 5 positions (12°, 16°, 20°, 25°, 42°)
• Dimensions:
  • Seat width: 480 mm
  • Height: 550 mm
  • Length: 315 mm → 580 mm (variable based on recline)
  • Suspension travel: 80 mm
• Mounting:
  • Track: 187 mm
• Upholstery:
  • Material: PVC
• Additional features:
  • Seat switch: No
  • Rotation: No
  • Joystick console: No
  • Lateral suspension: No
  • Seat heating: No
  • Safety belt system: Optional
