Granit
GRANIT Z50 Control Valve 2-Bank Double Acting Spring Return Code 87000921
GRANIT Z50 valve, 2x double acting (A-B closed), spring return. 40 l/min flow rate, 250 bar PN. P-T 1/2" BSP, A-B 3/8" BSP. Code 87000921.
Increase the versatility of your hydraulic system with our 2-Lever Hydraulic Control Valves (Distributors). These distributors allow you to manage two hydraulic circuits simultaneously or separately, offering superior control on tractors and agricultural and industrial machinery. They are essential for applications requiring the independent operation of two functions, ensuring reliability and precision in motion control.
Active filters
GRANIT Z50 valve, 2x double acting (A-B closed), spring return. 40 l/min flow rate, 250 bar PN. P-T 1/2" BSP, A-B 3/8" BSP. Code 87000921.
GRANIT Z50 valve: 1x double acting and 1x single acting (A-B closed / spring return). 40 l/min flow rate, 250 bar PN. P-T 1/2" BSP, A-B 3/8" BSP. Code 87001344.
GRANIT Z50 valve, 2x double acting, spring return. Ready for pressure beyond/carry-over (not installed). 40 l/min flow, 250 bar. Code 87001365.
GRANIT Z50 valve, 2x double acting: 1x spring return and 1x float position detented in all positions. 40 l/min flow, 250 bar. P-T 1/2" BSP. Code 87000980.
GRANIT Z50 valve, 2x double acting (A-B closed) with connection caps for Bowden cables. 40 l/min, 250 bar. P-T 1/2" BSP, A-B 3/8" BSP. Code 87000934.
GRANIT Z50 valve, 2x double acting, including 1x float position in pos. 3. 40 l/min flow rate, 250 bar PN. P-T 1/2" BSP, A-B 3/8" BSP. Code 87000930.
GRANIT Z50 valve, 2x double acting (1x float pos. 3) with connection caps for Bowden cables. 40 l/min, 250 bar. P-T 1/2" BSP, A-B 3/8" BSP. Code 87000928.
GRANIT Z50 valve, 2x double acting with joystick control. Features 1x float function in position 3. 40 l/min flow rate, 250 bar PN. Code 87000927.
GRANIT Z50 valve, 2x double acting with pressure beyond/carry-over function. 40 l/min flow rate, 250 bar PN. P-T 1/2" BSP, A-B 3/8" BSP. Code 87001367.
GRANIT Z50 valve, 2x double acting (A-B closed) with joystick/cross lever control. 40 l/min flow rate, 250 bar PN. P-T 1/2" BSP, A-B 3/8" BSP. Code 87000929.
