Multipurpose Rubber Hose | Internal Diameter: 20mm (3/4")

Multipurpose Rubber Hose | Internal Diameter: 20mm (3/4") - PRICE PER METER

This multipurpose rubber hose, rubberized both internally and externally, is ideal for applications requiring robustness and high resistance. Its construction ensures durability and reliability under various operating conditions.

Application Areas:

This multipurpose hose rubberized on the inside and outside is suitable for:

Construction and industry

Agriculture and mining

Liquids (including hot water) and compressed air

Irrigation and manure spreading

Sewer cleaning and cable protection

For heavy-duty use

Main Features:

Advantages:

Abrasion-resistant, robust, and durable.

Resistant to oil, gasoline, and chemicals (see resistance list).

Resistant to heat, aging, and ozone.

Very low pressure loss and low longitudinal expansion.

Very lightweight, flexible, and pressure-stable compared to mandrel-wrapped industrial hoses.

For heavy-duty use.

Insert Properties:

Warp: high-strength polyester.

Weft: polyamide / polyester; circular woven.

The special fabric construction guarantees low elongation, excellent delamination resistance, and significantly lower pressure loss compared to a 100% polyester fabric insert.

Fully embedded in the rubber lining for optimal protection against mechanical damage.

Internal and External Rubber:

High-quality NBR/PVC compound, pressed through the textile insert in a special extrusion process.

Special additives provide resistance to aging and ozone.

Inside: very smooth for minimal pressure loss.

Outside: ribbed for high abrasion resistance, heat protection.

Dimensions:

Internal Diameter: 20 mm (3/4")

Wall Thickness: 2 mm

Performance:

Working Pressure: 25 bar (Information applies to the hose only (water medium, 20°C). For hoses with fittings, the working pressure may be lower than indicated, due to the nominal pressure of the fittings or the type of installation. For compressed air, the maximum operating pressure is 25% of the burst pressure. Max. working pressure can only be provided by the manufacturer after clarifying the exact field of application.)

Burst Pressure: 75 bar

Temperature Range: Continuous operation from -20 °C to + 80 °C (water), temporarily up to + 100 °C (water).

Version: Tear resistance 1000 kg.

Suitable for food use: No.

Availability: Sold per meter (Standard roll length: 100 m).

Hose Type: Flat hose.
