High-resistance warning beacon **HELLA KL Rota LED Compact** with **LED technology**. It provides the **Flash** function and is powered by **multi-voltage (10V-30V)**, with a power consumption of only 10W. It is extremely robust, IP67/IPX9K certified, and mounted flexibly on a stem.
Technical Details
HELLA Part Number: 2XD 013 979-011
Lamp Type: LED
Type: KL Rota LED Compact
Light Function: Flash
Nominal Voltage (Range): 10 V - 30 V
Voltage (Nominal V): 12 V / 24 V
Power Consumption: 10 W
Current Consumption (A): 0.8 A (12V) / 0.4 A (24V)
Fixing: Flexible Stem Mount (DIN 14620)
Color: Yellow (Amber)
Protection Type (IP): IP 67, IP X9K (Maximum resistance to water and high-pressure/temperature washing)
Housing / Lens Material: ABS / Polycarbonate
Certification Mark: ECE-R65 TA 1, ECE-R10, SAE J845 Cl. 2, GGVSE / ADR
Dimensions and Other References
Outer Diameter: 165 mm
Total Height: 164 mm
Body Color: Black
Other Codes: 4550011276
Key Advantages
- **Extreme Durability:** IP 67 (temporary immersion) and IP X9K (high-pressure/high-temperature wash resistance) certifications.
- **R65 Class 1 Approval:** Guarantees superior light performance for emergency/hazard signaling.
- **Low Power Draw:** Only 10W of power consumption for extended battery life.
