The **Ellipse SACEX** rotating warning lamp is designed for agricultural and industrial vehicles. It features **multi-voltage (12V/24V)** power for maximum flexibility and uses a 21W halogen incandescent bulb for a bright and durable signal. The mounting is secured by a **rubberized base with a flexible stem** to withstand bumps and vibrations. It uses a tube mounting system for easy installation.
Technical Specifications
Nominal Voltage: 12 V / 24 V (Multi-Voltage)
Wattage (Bulb): 21 W
Bulb Type: Halogen Incandescent
Cover/Light Color: Yellow (Amber)
Rotation Mechanism: Worm Gear Drive
Base Type: Rubberized Base with Tube Fixing
Stem: Flexible
Cover (Lens): Impact-resistant Polycarbonate
Homologations: ECE R65 (Special Warning Light), R10 (EMC), RoHS, IP65 (Water/Dust Resistance)
Dimensions (Diameter x Height): 141 mm x 149 mm
Key Advantages
- **Multi-Voltage:** Works universally on both 12V and 24V systems.
- **Flexibility & Durability:** The flexible stem and rubberized base absorb shocks and protect the lamp from breakage.
- **R65 Approval:** Certifies the light signal's suitability for special road use.
- **Robust Construction:** Polycarbonate cover and IP65 rating against dust and water.
