BLUELINE 3771210B679 PTO Shaft Series B6 1210mm

3771210B679 BLUELINE PTO Drive Shaft Series B6 Lz 1210mm for Tractors up to 55HP

Blueline
3771210B679

BLUELINE B6 Series PTO Drive Shaft - L 1210mm (Code 3771210B679)

Hurry! only 3 items left in stock.
€210.00
Tax included
Quantity

Ready for delivery
Add to Compare
Add to Wishlist
  Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

  Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

  Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

The BLUELINE B6 Series drive shaft (1210 mm) is a professional Heavy Duty transmission component designed for high-power agricultural implements requiring extra reach. Featuring enlarged 30.2x91.5 mm cross kits and the "Italian System" telescopic profile, this model handles substantial nominal torque (710 Nm at 540 rpm), providing maximum durability for intensive field operations and modern tractor outputs.

Technical Specifications

Part Number: 3771210B679

Series: B6 (Standard Version)

Total Length (Lz): 1210 mm

Profile A (Tractor Side): 1 3/8" 6 Splines

Profile B (Implement Side): 1 3/8" 6 Splines

Cross Kit Dim. (Profile A/B): 30.2 x 91.5 mm

Locking System: Push-button / Push-button (P7/P9 Coupling)

Tube Profile: Italian System

Performance Data

Power at 540 rpm: Up to 55 HP (40 kW)

Power at 1000 rpm: Up to 83 HP (61 kW)

Nominal Torque (540 rpm): 710 Nm

Nominal Torque (1000 rpm): 580 Nm

Operating instructions are included. For 1.2-meter shafts, always ensure sufficient overlap between the inner and outer tubes during operation to prevent shaft separation or excessive vibration under load.
