PVC Spiral Hose | Inner Diameter: 60mm - Outer Diameter: 72mm
General Description: This is a highly flexible and robust PVC spiral hose designed for suction and pressure applications. Its composition makes it physiologically safe and suitable for contact with liquid foodstuffs, as well as for conveying potable water, sludge, slurry, and various other liquids in demanding conditions. Its spiral-reinforced construction makes it resistant to high vacuum and significant operating pressures.
Technical Specifications:
-
Inner Diameter (Ø internal): 60 mm
-
Outer Diameter (Ø external): 71 mm (Note: original description states 72mm in title and 71mm in details; 71mm is assumed as specific for other measurements)
-
Operating Pressure: 5 bar
-
Length: Meterware (sold by the meter)
-
Bending Radius: 180 mm
-
Vacuum (Depression): 0.9 bar
-
Wall Thickness: 5.5 mm
-
Temperature Range: -5°C to +65°C (Note: the thermal resistance under inner layer material specifies -15°C to 60°C; both specified ranges are provided)
-
Hose Type: Spiral hose
-
Food Grade: Yes
Materials:
-
Inner Layer Material: Soft PVC, smooth, transparent color.
-
Outer Layer Material: Soft PVC, smooth, transparent color.
-
Reinforcement: Steel spiral.
Compliance and Standards:
-
EN ISO 1307:2008
-
EU 1935/2004 (Materials and articles intended to come into contact with food)
-
EU 10/2011 Categories A, B, C (Plastic materials and articles intended to come into contact with foodstuffs)
-
LFGB (German Food and Feed Code)
Typical Applications: Ideal for suction and conveying of water (including industrial), sludge, manure, and other liquids. Particularly suitable for transporting liquid food products due to its certifications. Often used on slurry injectors in agriculture.
Tolerances:
-
Length: ± 5%
-
Inner Diameter: ± 2%
PRICE PER METER
