Faster NV Series 1" BSP DN25 Male Quick Coupling

Faster NV Series 1" BSP DN25 Male Quick Coupling

Faster
86001010

Faster NV Series 1" BSP DN25 Male Quick Coupling

Out of Stock
€25.90
Tax included
Quantity

Processing in approximately 2-3 working days
  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Faster Male Quick Coupling Series NV 1" BSP DN25

Features:

Nominal width: DN 25

Series: 6

Threaded connection: 1" BSP

Flow rate (l/min): 220

PN (bar): 250

A (mm): 30.3

C (mm): 39

H (mm): 31.3

AC1 (mm): 41

Weight: 284 g

BSP, NPT, UNF, internal thread

Agricultural use

Faster standard. Only for NV-12 according to ISO 7241-1 A

Material: steel, chromium VI-free coating

Temperature range: -25°C up to 125°C.

Connect / disconnect only by pulling back the clamping sleeve, no tear-off function.

Not pressurized.

Ref. Orig.: NV1GASM
