Deep groove ball bearing 16101 SKF 12x30x8 mm open
SKF deep groove ball bearing part number 16101, single row design with 12 mm bore diameter, 30 mm outer diameter, and 8 mm width. Manufactured from bearing steel with a sheet metal cage, cylindrical bore, and standard CN clearance, providing smooth rotation, durability, and accurate fit for industrial applications.
Read more ↓- Open design
- Narrow 160-series cross-section
- Pressed steel cage
€12.50VAT incl.
⚡ Limited-time deal
00days
:00hrs
:00min
:00sec
Coupon
-€0.25
-2% sul carrello
Sconto extra riservato ai clienti registrati
Accedi per sbloccare il codicePrezzo finale con coupon: €12.25
Not sure it fits?Message us with your tractor model
WhatsAppSecure paymentsEasy returnsFree shipping over €30 + VAT
Description
SKF deep groove ball bearing 16101 - 12x30x8 mm
SKF narrow section single-row deep groove ball bearing, commercial part number 16101. Engineered to accommodate radial loads and moderate axial loads in both directions, it ensures smooth rotation with low operational friction. It features an open design without seals, a 12 mm cylindrical bore, a 30 mm outside diameter, and a slim 8 mm width. Made from bearing steel with a pressed sheet metal cage and standard CN radial internal clearance, it is ideal for rotary components in industrial machinery, agricultural equipment, and gearboxes.
Key features
Open designUnshielded construction suitable for oil bath environments or sealed bearing housings with continuous external lubrication.
Narrow 160-series cross-sectionCompact width of only 8 mm designed to fit into axially restricted mechanical assemblies.
Pressed steel cageFormed sheet metal cage for precise ball guidance and dependable operation at high rotational speeds.
ISO dimensional toleranceStandard precision class ensuring seamless interchangeability and reliable press fitting onto 12 mm shafts.
Specifications
| Commercial part number | 16101 |
|---|---|
| Product brand | SKF |
| Type | Single-row deep groove ball bearing |
| Bore diameter | 12 mm |
| Outside diameter | 30 mm |
| Width | 8 mm |
| Bore type | Cylindrical |
| Number of rows | 1 |
| Sealing | Open (none) |
| Cage material | Sheet metal |
| Radial internal clearance | CN (Normal) |
| Bearing material | Bearing steel |
| Snap ring groove | Without |
| Relubrication feature | Without |
| Inner ring shoulder diameter (d1) | 17 mm |
| Outer ring recess diameter (D2) | 24.72 mm |
| Minimum chamfer dimension (r1,2) | 0.3 mm |
| Tolerance class | Normal |
Fitting tipsBefore fitting, verify that shaft seatings and housing bores are clean, deburred, and lightly oiled to facilitate smooth positioning. Apply mounting force strictly to the ring that has the interference fit (the inner ring when pressing onto a shaft), never transmitting force through the rolling elements. As this is an open bearing, apply initial grease prior to closing the assembly or ensure the unit receives proper oil delivery from the sump.
