Rubber silentblock 40x230 part 55907 for 80x80 mm frame support

Rubber silentblock damping element part number 55907 measuring 40x230 mm, designed for disc harrow arm supports mounted on 80x80 mm frame bars. Manufactured from high density elastomer, it efficiently absorbs mechanical shocks, dampens field vibrations, and protects the implement frame and bearing assembly from overload during heavy soil tillage operations.

High-density elastomeric rubber
Progressive multi-directional tripping
80x80 mm frame fitment

€15.90VAT incl.

Coupon -€0.32 -2% sul carrello

Sconto extra riservato ai clienti registrati

Accedi per sbloccare il codice

Prezzo finale con coupon: €15.58

Not sure it fits?Message us with your tractor model

Secure paymentsEasy returnsFree shipping over €30 + VAT

Description

Rubber silentblock dampening cord 40x230 mm for 80x80 mm frame carrier arm - Part number 55907

Replacement elastomeric rubber silentblock dampening cord for disc carrier arms and independent suspension legs on compact disc cultivators, commercial part number 55907. Engineered specifically to fit housing channels on 80x80 mm square frame tube attachments, it provides multi-directional elastic suspension for individual disc elements. It effectively absorbs severe shock loads, stone strikes, and continuous ground vibrations, preventing frame stress and structural cracking during high-speed field operations. Formulated from high-density vulcanized rubber with exceptional resistance to compression set, weathering, and ozone degradation, it ensures immediate return of the disc arm to its working position following obstacle deflection. Features a diameter of 40 mm and a length of 230 mm.

Key features

High-density elastomeric rubberHeavy-duty vulcanized compound formulated to sustain extreme compression cycles and resist abrasive environmental wear.

Progressive multi-directional trippingDelivers flexible shock absorption, allowing the disc arm to trip over rocks without interrupting field travel.

80x80 mm frame fitmentPrecision-sized to seat securely inside the housing channels of front and rear disc carrier arms clamped on 80x80 mm square beams.

Frame stress reductionDampens high-frequency vibrations and peak torsional shock loads transferred to the implement frame structure.

Calibrated 40x230 mm dimensionsSized to maintain uniform pre-load compression inside the arm clamp assembly.

Specifications

Commercial part number	55907
Product type	Rubber silentblock dampening cord / pad
Material	High-density anti-aging rubber elastomer
Diameter (Ø)	40 mm
Length	230 mm
Compatible frame profile	80x80 mm

Fitting tipsPrior to installing the new silentblock cords, thoroughly clean the internal channels of the disc arm housing and 80x80 mm frame clamp, removing dirt, rust, and remnants of worn rubber. Inspect the housing interior for sharp metal burrs that could cut or score the elastomeric surface during insertion. To facilitate smooth installation of the 40x230 mm cords into their retention pockets, apply a thin coat of neutral liquid soap or specialized rubber assembly lubricant (do not use petroleum-based grease or oil as they cause rubber swelling and premature degradation). Position all four dampening cords evenly, ensuring complete alignment within their seats before tightening the clamp bolts to specification.
