DonaldsonRef.
Donaldson Spin-On Hydraulic Filter P583540 19 Micron John Deere
The Donaldson P583540 spin-on hydraulic filter with Synteq XP media provides advanced protection. Beta 1000 efficiency at 19 microns, outer diameter 157.5 mm, length 258.3 mm. Fits John Deere.
Read more ↓- Synteq XP™ Technology
- Beta 1000 Efficiency (19 Micron)
- Integrated Bypass Valve
€140.00VAT incl.
⚡ Limited-time deal
00days
:00hrs
:00min
:00sec
Coupon
-€2.80
-2% sul carrello
Sconto extra riservato ai clienti registrati
Accedi per sbloccare il codicePrezzo finale con coupon: €137.20
Not sure it fits?Message us with your tractor model
WhatsAppSecure paymentsEasy returnsFree shipping over €30 + VAT
Description
The Donaldson P583540 spin-on hydraulic filter with Synteq XP media provides advanced protection. Beta 1000 efficiency at 19 microns, outer diameter 157.5 mm, length 258.3 mm. Fits John Deere.
Key features
Synteq XP™ TechnologyAdvanced synthetic filter media developed and rigorously tested by Donaldson to deliver superior filtration efficiency.
Beta 1000 Efficiency (19 Micron)Effectively traps harmful microscopic particles, safeguarding the longevity of pumps, valves, and hydraulic controls.
Integrated Bypass ValveSet at 2 Bar (29 PSI) to ensure continuous fluid flow during cold starts or under clogging conditions.
Robust ConstructionWithstands compression/expansion ratings up to 5 Bar (73 PSI) with a spin-on design for safe and easy maintenance.
Specifications
| Donaldson Product Code | P583540 |
|---|---|
| Component Type | Spin-On Hydraulic Cartridge Filter |
| Filter Media Type | Synthetic (Synteq XP™) |
| Filtration Efficiency | Beta 1000 - 19 Micron |
| Outer Diameter | 157.5 mm (6.20 Inches) |
| Length / Height | 258.3 mm (10.17 Inches) |
| Thread Size | M140 x 4 |
| Gasket Inner Diameter (ID) | 145.6 mm (5.73 Inches) |
| Bypass Valve | Yes (Setting: 2 Bar / 29 PSI) |
| Compression / Expansion Rating | 5 Bar (73 PSI) |
