Seat shock absorber 240136195 Grammer John Deere AL67516 G136195

iPhotos are indicative: the product may differ in some details. Refer to the specifications.

GrammerRef. OEM OEM OEM

Seat shock absorber 240136195 Grammer John Deere AL67516 G136195

Grammer tractor seat shock absorber part number 240136195, matching OEM references G136195, 136195, and John Deere AL67516 for 50 series 2850. Fits MSG 83, MSG 93, LS 95, DS 50 suspensions and Compacto seats, featuring an 8 mm eyelet diameter, 24 mm tube body, and an adjustable operating length from 155 to 220 mm.

Fits

GRAMMER, John DeereGRAMMER seat suspensionsGRAMMER Compacto seat seriesGRAMMER upper seat sectionsJohn Deere 50 Series tractors

See full table ↓

€85.00VAT incl.

Coupon -€1.70 -2% sul carrello

Sconto extra riservato ai clienti registrati

Accedi per sbloccare il codice

Prezzo finale con coupon: €83.30

Not sure it fits?Message us with your tractor model

Secure paymentsEasy returnsFree shipping over €30 + VAT

Description

Shock absorber for GRAMMER MSG, Compacto, John Deere seats - Part number 240136195

Replacement hydraulic shock absorber for mechanical and air suspension seats, commercial part number 240136195. Engineered to effectively damp shocks, vibrations, and vertical jolts during agricultural and construction machinery operation, it restores optimal suspension damping and operator ergonomics. Compatible with GRAMMER MSG 83, MSG 93, LS 95, and DS 50 suspensions, Compacto seat range, 511, 521, and 721 upper seat structures, and John Deere 50 Series tractors (model 2850). It features 8 mm mounting eyelets, a 24 mm body diameter, and an operating length range between 155 mm and 220 mm.

Key features

Effective oscillation dampingSmoothes out ground shocks and continuous oscillations, safeguarding seat suspension linkages from premature wear.

Calibrated 155 - 220 mm dimensions65 mm working stroke precisely engineered for GRAMMER and John Deere seat suspension mechanisms.

Standard 8 mm eyelet holes8 mm inner diameter eyelet bushings ensuring a snug fit onto seat linkage mounting pins without lateral play.

Direct OEM interchangeabilityStraight replacement for GRAMMER OEM reference G136195 and John Deere part numbers 136195, AL67516.

Compatibility

GRAMMER seat suspensions	MSG 83MSG 93LS 95DS 50
GRAMMER Compacto seat series	CompactoCompacto Basic MCompacto Basic SCompacto Basic WCompacto Comfort MCompacto Comfort SCompacto Comfort W
GRAMMER upper seat sections	511521721
John Deere 50 Series tractors	2850

Specifications

Commercial part number	240136195
OEM reference	G136195, 136195, AL67516
Product brand	GRAMMER
Machine manufacturer	GRAMMER, John Deere
Eyelet hole diameter	8 mm
Body diameter	24 mm
Min. - max. length	155 - 220 mm
Product type	Seat shock absorber

Fitting tipsBefore beginning replacement, completely lower or release air pressure from the seat suspension to relieve all mechanical tension from the mounting pins. Withdraw the retaining pins or bolts, take out the worn damper, and clean the mounting brackets thoroughly. Align the 8 mm eyelets of the new shock absorber with the suspension brackets, ensuring the 24 mm body has full clearance through its movement range. Reinsert the mounting pins with a light film of grease and secure retaining clips or nuts, checking that the seat moves freely throughout its 155 to 220 mm travel range.
