BLUELINE 3771210B234 PTO Shaft Series B2 1210mm

3771210B234 BLUELINE PTO Drive Shaft Series B2 Lz 1210mm for Tractors up to 27HP

Blueline
3771210B234

BLUELINE B2 Series PTO Drive Shaft - L 1210mm (Code 3771210B234)

Hurry! only 2 items left in stock.
€119.90
Tax included
Quantity

Last items in stock
Add to Compare
Add to Wishlist
  Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

  Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

  Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

The BLUELINE B2 Series drive shaft (1210 mm) is a high-quality power transmission component designed for agricultural implements requiring a long-reach connection. Featuring reinforced 24x61 mm cross kits and an "Italian System" tube profile, this standard version offers superior torque capacity (up to 350 Nm) and reliable push-button coupling on both ends.

Technical Specifications

Part Number: 3771210B234

Series: B2 (Standard Version)

Total Length (Lz): 1210 mm

Profile A (Tractor Side): 1 3/8" 6 Splines

Profile B (Implement Side): 1 3/8" 6 Splines

Cross Kit Dim. (Profile A/B): 24 x 61 mm

Locking System: Push-button / Push-button (P3/P4 Coupling)

Tube Profile: Italian System

Performance Data

Power at 540 rpm: Up to 27 HP (20 kW)

Power at 1000 rpm: Up to 40 HP (30 kW)

Nominal Torque (540 rpm): 350 Nm

Nominal Torque (1000 rpm): 285 Nm

Safety and operating instructions are included. For extra-long shafts, ensure correct overlap of the inner and outer tubes to prevent shaft separation or vibration.
