Antistatic Polyurethane Flexible Hose | Inner Diameter: 2 3/4" / 70mm
General Description: This is a highly flexible and robust polyurethane (PU) spiral hose with antistatic properties. It is ideal for the suction and conveyance of abrasive materials such as dust, granules, chips, and fibers, especially in environments where preventing electrostatic charge build-up is critical. Its abrasion resistance and flexibility make it suitable for a wide range of industrial applications.
Technical Specifications:
-
Inner Diameter (Ø internal): 70 mm (2 3/4")
-
Outer Diameter (Ø external): 83 mm
-
Max Operating Pressure: 2 bar
-
Vacuum (Depression): 0.55 bar
-
Bending Radius: 70 mm
-
Weight: 890 g/m
-
Wire Thickness (Spiral): 1.8 mm
-
Wall Thickness: 1.4 mm
-
Temperature Range: -40°C to +90°C
-
Hose Type: Spiral hose
-
Roll Length: 20 m
-
Length (availability): Meterware (sold by the meter)
-
Suitable for Food Use: No
Materials:
-
Hose Body: Polyurethane (PU)
-
Reinforcement: Embedded spiral (typically spring steel, although not specified, it's standard for this hose type)
-
Additional Properties: Antistatic
Typical Applications: Ideal for the woodworking industry, plastics industry, industrial vacuum systems, pneumatic conveying of abrasive materials, air conditioning and ventilation systems, and all applications where high abrasion resistance and electrostatic charge dissipation are required. Not suitable for food applications.
PRICE PER METER
