Donaldson P551603 Spin-On Full-Flow Engine Oil Filter 3/4-16
iPhotos are indicative: the product may differ in some details. Refer to the specifications.
DonaldsonRef.

Donaldson P551603 Spin-On Full-Flow Engine Oil Filter 3/4-16

Donaldson P551603 heavy-duty spin-on full-flow lube filter, outer diameter 108 mm, length 170 mm, with 3/4-16 UNF thread. Delivers 99% filtration efficiency at 23 microns and includes an integrated anti-drainback valve plus internal bypass valve set at 2.1 bar. Replaces OEM cross-references Fiat CNH Iveco 1909101, Same 244191701, Perkins 993028, JCB 44647402, Caterpillar 3I1246, and Purflux LS412. Provides optimal lubrication protection for agricultural and industrial equipment.

  • Donaldson High-Efficiency Filtration
  • Integrated Anti-Drainback Valve
  • Internal Safety Bypass Valve (2.1 bar / 30 PSI)
€21.00VAT incl.
Coupon -€0.42 -2% sul carrello

Sconto extra riservato ai clienti registrati

Accedi per sbloccare il codice

Prezzo finale con coupon: €20.58

Not sure it fits?Message us with your tractor model
WhatsApp
Secure paymentsEasy returnsFree shipping over €30 + VAT

Description

Donaldson P551603 heavy-duty spin-on full-flow lube filter, outer diameter 108 mm, length 170 mm, with 3/4-16 UNF thread. Delivers 99% filtration efficiency at 23 microns and includes an integrated anti-drainback valve plus internal bypass valve set at 2.1 bar. Replaces OEM cross-references Fiat CNH Iveco 1909101, Same 244191701, Perkins 993028, JCB 44647402, Caterpillar 3I1246, and Purflux LS412. Provides optimal lubrication protection for agricultural and industrial equipment.

Key features

Donaldson High-Efficiency FiltrationCertified 99% efficiency at 23 microns captures fine soot, dirt, and metal particles to protect critical engine bearings and journals.
Integrated Anti-Drainback ValvePrevents oil drainage when the engine is turned off, ensuring immediate pressurized oil delivery at start-up to avoid dry friction.
Internal Safety Bypass Valve (2.1 bar / 30 PSI)Guarantees uncompromised oil flow during cold starts with thick fluid or under high differential pressure conditions.
Robust Pressure Surge ResistanceHeavy-gauge metal canister and internal tube withstand operating collapse/burst pressures up to 6.9 bar (100 PSI).
Precision Elastomeric GasketHigh-integrity sealing ring (OD 72 mm / ID 62 mm) eliminates leaks and withstands extreme operating thermal cycles.

Specifications

Brand / ManufacturerDonaldson
Product Part NumberP551603
Filter Style / TypeFull-flow lubricant filter, spin-on canister
Outer Diameter108 mm (4.25 inches)
Overall Length170 mm (6.69 inches)
Thread Size3/4-16
Gasket DimensionsOuter Diameter (OD): 72 mm (2.83 in) | Inner Diameter (ID): 62 mm (2.44 in)
Filtration Efficiency99% at 23 Micron
Media TypeResin-impregnated high-grade cellulose
Anti-Drainback ValveYes
Bypass Valve SettingYes, preset at 2.1 bar (30 PSI)
Burst / Collapse Pressure6.9 bar (100 PSI)
