Figure 7 - 8x20 Underhead Square Screw for Amazone ZA-F, ZA-FR Fertilizer Spreaders

Figure 7 - 8x20 Underhead Square Screw for Amazone ZA-F, ZA-FR Fertilizer Spreaders

Specifications:

Ø D (mm): 8

• DIN: 603

• Thread: M8

• Thread pitch: 1.25

• Head Ø (mm): 20.65

• Length (mm): 20

• Material: Stainless steel (V2A)

• Shaft Ø (mm): 8

• b (mm): 22

• Type: Round head screws with square underhead

• F (mm): 5.6

• v (mm): 8.58

• Head: Half round

• Tensile strength (N/mm²): 700

• Thread type: Standard thread

• Head shape: Flat round head

• Head height (mm): 4.88

• Thread direction: RH

APPLIED TO THE FOLLOWING BRANDS AND MODELS:

AMAZONE: ZA-F, ZA-FR
