Figure 10 - Hex Screw M8x16 for Amazone ZA-F, ZA-FR Fertilizer Spreaders

Figure 10 - Hex Screw M8x16 for Amazone ZA-F, ZA-FR Fertilizer Spreaders

Specifications:

Ø D (mm): 8

• Drive: External hexagon

• DIN: 933

• Thread: M8

• Thread pitch: 1.25

• Length (mm): 16

• Material: Stainless steel (V2A)

• S (mm): 13

• ISO code: 4017

• a (mm): 3.75

• Type: Hex head screw

• Tensile strength (N/mm²): 700

• Drive (mm): 13

• Thread type: Standard thread

• Head shape: Hexagon head

• Head height (mm): 5.3

• Thread direction: RH

APPLIED TO THE FOLLOWING BRANDS AND MODELS:

EK-S 00, EK 00 & 01, EK-W 00, EK-SH 00, ZA-F, ZA-FR, ZA-M 900, ZA-M 1200, ZA-M 1500 / profis, ZA-M Hydro, ZA-M Compact, ZA-M MAX, ZA-M I+II, ZA-M premiS, ZA-M noviS, ZA-M maxiS, ZA-M profiS, ZA-M Ultra, ZA-U, ZA-X Perfect, ZA-X, ZA-XW Perfect 02, ZA-XS 02
