Universal Ambidextrous (Left and Right Hand) Outer Cabin Door Handle for Deutz-Fahr Tractors & Combines - Part Number: 65404011
The universal ambidextrous exterior cab door handle (reversible LH / RH mounting) (part number 65404011, genuine Deutz-Fahr and SAME Deutz-Fahr OEM references 04378982, 04362172, 2.0114.011.2) is an authentic OEM-grade ergonomic manual release assembly designed to actuate the cabin door latch mechanisms (compatible with LH latch 65404012, RH latch 65404013, and release push-button 65404080) across Deutz-Fahr StarCab, MasterCab, and combine harvester cabins. Fabricated from high-impact, UV-stabilized structural polymer with wear-resistant internal pivot linkages and a corrosion-resistant steel return spring, it provides a firm, ergonomic grip even in demanding agricultural operations when wearing thick work gloves. Its symmetrical and reversible architecture permits straightforward mounting on either the left-hand (driver side) or right-hand (passenger side) door, while the dedicated perimeter base gasket ensures reliable sealing against rainwater, field mud, and fine dust ingress. This OEM-equivalent replacement offers direct plug-and-play fitment across widespread Deutz-Fahr machines (Actor, AgroPrima, AgroStar, AgroXtra, DX, DX 3, DX 4, DX 6, DX 7 series tractors, and Topliner series combine harvesters).
Key Features & Engineering Advantages
- Reversible Ambidextrous Architecture (LH / RH): Symmetric modular construction permits universal mounting on either the left or right cab door, streamlining fleet inventory and preventing workshop assembly errors.
- UV-Stabilized High-Impact Technopolymer: Engineered from heavy-duty structural polymer designed to withstand severe thermal swings (-30°C to +80°C), intensive sunlight exposure, diesel fuel, agrochemicals, and frequent high-pressure steam cleaning.
- Smooth & Responsive Unlatching Action: Calibrated internal mechanism fitted with a high-resilience return spring delivers crisp, low-effort door opening free of sticking or excessive mechanical free-play.
- Factory-Accurate Alignment: Mounting hole centers and stud profiles strictly conform to original Deutz-Fahr door frame specifications, allowing quick bolt-on replacement without drilling or alterations.
- Molded Environmental Base Gasket Included: High-grade perimeter elastomer gasket seals the handle-to-door sheet interface, blocking rainwater, mud spray, and abrasive field dust from entering the interior door frame.
Technical Specifications
| Commercial Part Number |
65404011 |
| Mounting Location / Side |
Ambidextrous – Left and Right Doors (LH / RH) |
| Deutz-Fahr / SDF OEM References |
04378982, 04362172, 2.0114.011.2 |
| Component Classification |
Exterior cabin door handle assembly |
| Cab Enclosure Application |
Cabins StarCab, MasterCab, and Deutz-Fahr combine enclosures |
| Material Composition |
UV-stabilized structural technopolymer with internal metal pivot pins and steel return spring |
| Actuation Method |
Mechanical manual release to operate the door latch mechanism |
| Matching Latches and Components |
Compatible with LH latch 65404012, RH latch 65404013, and push-button 65404080 |
Equipment Compatibility & Machine Application Guide
| Manufacturer |
Machine Series |
Supported Models & Combines |
| Deutz-Fahr |
Actor Series |
Actor 5510, Actor 5520 |
| AgroPrima Series |
AgroPrima 4.31, AgroPrima 4.51, AgroPrima 4.56, AgroPrima 6.06, AgroPrima 6.16 |
| AgroStar Series |
AgroStar 4.61, 4.68, 4.71, 4.78, 6.08, 6.11, 6.21, 6.28, 6.31, 6.38, 6.61, 6.71, 6.81 |
| AgroXtra Series |
AgroXtra 3.57, AgroXtra 4.07, AgroXtra 4.17, AgroXtra 4.47, AgroXtra 4.57, AgroXtra 6.07, AgroXtra 6.17 |
| DX & DX 7 Series |
DX 160, DX 230, DX 250 • DX 7.10 |
| DX 3 Series |
DX 3.10, DX 3.30, DX 3.50, DX 3.60, DX 3.65, DX 3.70, DX 3.80, DX 3.90 |
| DX 4 Series |
DX 4.10, DX 4.30, DX 4.50, DX 4.70 |
| DX 6 Series |
DX 6.05, DX 6.10, DX 6.30, DX 6.50 |
| Topliner Combines Series |
Topliner 8 XL, Topliner 4060, Topliner 4065, Topliner 4068, Topliner 4075, Topliner 4080, Topliner 4090 |
Installation Advice & Workshop Notes: Before installation, dismantle the interior door pillar trim or cover to access the rear mounting studs and carefully release the linkage rod retaining clip connected to the door latch mechanism (65404012 on LH or 65404013 on RH). Clean the door mounting surface of old sealant residue, dirt, and road grime. Seat the supplied perimeter rubber gasket properly against the door sheet metal to ensure a weather-tight barrier against water and dust infiltration. Fasten mounting nuts progressively and evenly to avoid over-torquing or distorting the technopolymer housing. Finally, verify that the release mechanism maintains approximately 1–2 mm of free play before engaging the latch pawl, ensuring light, smooth opening action and positive perimeter weatherseal compression upon closure.
