OlivGreen 700 Plus Carbon Telescopic Ultralight 12V Electric Olive Harvester - Model: OG700S-PLUS CARBON / Part Number: MEOG700CSPLUS

The OlivGreen 700 Plus Carbon ultralight battery-powered olive harvester (model OG700S-PLUS CARBON, commercial part number MEOG700CSPLUS)[cite: 3] is a professional harvesting tool engineered with a high-rigidity carbon fiber telescopic pole to minimize operator strain. Designed to operate efficiently across various olive cultivars and canopy densities (from pruned orchards to dense, unmanaged trees), it utilizes an opposed elliptical dual-comb movement to ensure high harvest yields without excessive defoliation. The machine is perfectly balanced thanks to the 12V electric motor with replaceable brushes and gear reducer housed directly in the base handle. Equipped with a carbon telescopic pole adjusting from 1.7 to 2.2 meters with a quick-locking system[cite: 3], a safety lockout ON/OFF switch, and a 13-meter extension power cable, it delivers high harvesting productivity of 85 – 105 kg/h[cite: 3] with a featherlight total weight of just 2.3 kg[cite: 3].

Key Features & Operational Advantages

• Ultralight Carbon Fiber Pole (Record 2.3 kg Weight): High-modulus carbon fiber construction reduces overall machine weight to only 2.3 kg[cite: 3], significantly lessening physical fatigue during continuous daily use.
• Adjustable Telescopic Reach (1.7 > 2.2 m): Carbon telescopic pole equipped with an ergonomic quick-locking cam mechanism[cite: 3], allowing rapid height adjustment directly from ground level.
• Opposed Elliptical Dual-Comb Kinematics: Fast 1,200 beats per minute (bpm) beating frequency[cite: 3] that glides smoothly into the foliage, detaching olives cleanly without harming bark or young fruiting shoots.
• Handle-Mounted Motor & Gearbox: The 12V motor with easily replaceable carbon brushes and reduction gear is positioned in the base handle, providing optimal weight distribution and keeping the harvesting head nimble.
• High Harvesting Output (85 – 105 kg/h): Strong hourly harvesting capacity[cite: 3] suited for professional operations across various olive cultivars and ripeness levels.
• Low Power Consumption (6 – 8 Ah): Average current draw of only 6 to 8 Ah[cite: 3], allowing full-day autonomy when connected to standard 12V lead-acid batteries (60–80 Ah)[cite: 3].
• Heavy-Duty 13-Meter Extension Cable: High-grade insulated extension wire with battery alligator clamps, offering wide maneuvering freedom around the canopy.
• Safety Lockout ON/OFF Switch: Built-in safety system on the power switch to avoid accidental motor start-ups during tool repositioning or transit.

Technical Specifications

Orchard Suitability & Application Scope

Grove / Canopy Environment	Operational Advantages (Carbon 2.3 kg Version)
Prolonged & Full-Day Harvesting Shifts	Ultralight 2.3 kg weight[cite: 3] reduces physical fatigue for professional operators working long hours across large acreages
Intensive & Pruned Groves	The 1200 bpm beating frequency[cite: 3] combined with agile carbon maneuverability enables rapid, precise sweeps through fruiting wood
Dense or Unpruned Foliage	Opposed elliptical kinematics penetrate tangled canopies to shake free interior fruit while keeping defoliation to a minimum

Operating Guidelines & Workshop Maintenance Notes: Before starting, connect the clamps of the 13 m cable to a charged 12V battery (recommended 60–80 Ah)[cite: 3], observing strict polarity (red to positive, black to negative). Adjust the carbon telescopic pole to the desired working length (1.7 – 2.2 m)[cite: 3] and tighten the quick-lock lever securely before use. Activate the safety ON/OFF switch and guide the combs downward through the branches, avoiding excessive levering against heavy wood to protect the reduction gearbox. After finishing work, clean the harvesting head of leaves and debris using compressed air, inspect tine tightness, and regularly check the wear status of the replaceable motor carbon brushes.
