Arag ISO 11786 Tractor Speed Sensor Cable 5m 467100.091 | Raim Store

Arag Tractor ISO 11786 Speed Signal Interface Cable 5 Metres Part 467100.091

star star star star star_border
Arag
27657

The Arag speed signal interface cable (part number 467100.091) measures 5 metres (16.4 ft) in length and links directly to the standardized ISO 11786 in-cab tractor outlet. This connection enables Arag spray computers and monitors to utilize the tractor's integrated factory radar or transmission speed sensor as a highly accurate speed source, eliminating the need to install aftermarket wheel magnets or external sensors.

Hurry! only 1 items left in stock.
€94.90
Tax included
COUPON
- € 1,90
Final price: € 93,00
Quantity

Last 1 items
Add to Compare
Add to Wishlist
Security Policy
Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy
Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments
Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

Arag ISO 11786 Tractor Speed Signal Interface Cable (5 m) - Code 467100.091

The professional-grade Arag speed signal readout cable (Product Code: 467100.091) is a precision electronic interface harness developed to connect Arag onboard control systems and flow rate consoles directly to the standardized ISO 11786 data signal port built into modern tractor cabs. Utilizing this established communication link allows the spray rate controller to employ the tractor's factory-installed radar or transmission speed sensor as the core ground-speed velocity indicator, optimizing field application accuracy without demanding auxiliary external hardware.
Design Details and Electronic Functionality
This technical signal harness is engineered with heavy-duty dielectric insulation compounds and incorporates internal structural shielding developed explicitly to isolate and block electromagnetic interference (EMI) generated by high-power vehicle alternator and engine circuits. By interfacing directly with the tractor's standard ISO 11786 female outlet socket, the cable extracts high-frequency pulses matched to the actual true ground speed recorded by the vehicle's onboard radar. This method completely isolates measurement discrepancies caused by dynamic tire slippage or wheel spin in soft, wet, or waterlogged field substrates. The extracted frequency data feeds instantly into Arag flow management computers, enabling immediate proportional response adjustments of motorized spray control valves to lock in constant volumetric chemical application rates (L/ha). With a robust 5-meter longitudinal extension, the cable profile provides ample length for clean, strain-free routing inside structural cab panels.
Technical Specifications
Component Classification Electronic interface signal harness for tractor radar speed acquisition
Connection Compliance Standard ISO 11786 (Standard tractor diagnostic/signal socket)
Harness Length Specification 5 meters (16.4 ft)
Signal Data Source Onboard vehicle radar unit or integrated primary powertrain velocity sensor
Arag Master Unit Compatibility Bravo series computers (Bravo 180S, Bravo 350, Bravo 400S), Delta displays, and precision regulation modules
Insulation Shielding Grade Abrasion-resistant flexible outer sleeve with integrated anti-EMI internal shielding layers
Product Reference Code 467100.091
Precision Farming Fleet Optimization Vantaggi
Technical Metric Operational Benefit & Fleet Integration
Slip-Error Suppression By reading direct vehicle radar inputs, calculated flow adjustments track actual physical velocity over ground, eliminating dosing faults linked to heavy wheel-spin.
Plug-and-Play Application Bypasses the installation, gap calibration, and maintenance of traditional wheel-hub magnet sensors, shortening workshop implementation windows.
Extended Layout Safety The 5-meter development allows for seamless routing under floor mats and behind mechanical consoles, guarding the copper path from stress under high operator usage.
