Arag Bravo 180S Crop Spraying Computer (3 Sections / 3 Ways) - Code 467180301
The professional-grade Arag Bravo 180S on-board computer (Product Code: 467180301), engineered explicitly in its dedicated crop spraying version, is a compact and cost-effective yet exceptionally efficient and precise regulation console. Tailored to satisfy the exact field requirements of managing small-to-medium field sprayers, crop booms, and weeding implements, this electronic control module optimizes agrochemical distribution, monitors line dynamics in real time, and eliminates active ingredient waste.
Design Details and Spray Loop Automations
The technical core of the Bravo 180S Crop Spraying configuration delivers dynamic and intelligent command over a 3-way fluid manifold system. The device carries out automated proportional dosage adjustments by cross-referencing flow rate or pressure data provided by inline flowmeters or pressure transducers. The internal software architecture supports automated tank profile calibration via fill-line flowmeters, allowing operators to export accurate volumetric metrics via a secured USB interface. To lock in high-precision field applications, the computer incorporates two structural safety fail-safes: an automated spray lock that shuts off flow if system pressure falls below a pre-set minimum limit (preventing nozzles from operating outside their ideal atomization and droplet distribution charts), and an automatic master valve shut-off triggered when tractor travel speed drops below the user-defined operational threshold. The robust internal memory stores up to 10 separate job profiles (dosage constants, nozzle classifications, etc.) for instant recall, while providing the field flexibility to momentarily increase or decrease target spray distribution values on the go.
Technical Specifications
| Component Classification |
Digital electronic regulation and monitoring computer for crop sprayers and weeding booms |
| Hydraulic Output Layout |
3 Ways / 3 Independent spray line control sections |
| Job Profile Logging |
Stores up to 10 distinct programmable and recallable operational presets |
| Interfaces and Connectivity |
Sealed USB data port for logging and updates, GPS receiver port, remote master valve switch input |
| Master Display Linkage |
Triggers automatic master valve shut-off when linked to Bravo 400S or Delta 80 smart screens |
| Technical Parameters Monitored |
Target dosage, machinery ground speed, operational line pressure, instant flow rate, total volume distributed, integrated tank fluid level, treated area, duration of application, total distance traveled |
| User-Defined Application Metrics |
L/ha, GPA, GPK, L/100m, etc. (Multi-language software) |
| Product Reference Code |
467180301 |
Integrated Safety Features and Fluid-Dynamic Alarms
- Tank Level Tracking: Features a factory-configured tank level interface, ready to hook up with an optional fluid sensor for ultra-precise volumetric readings.
- Hydraulic Minimum Pressure Lock: Halts chemical output immediately if pressure parameters fall below thresholds, protecting the line from poor micronization or irregular boom coverage.
- Visual & Acoustic Warning Interface: Triggers instant alarms if flow rates or speed parameters deviate from the pre-set field application coordinates.
