Arag Bravo On-Board Computer Main Power Cable (3 m) - Code 467305.081

The professional-grade Arag main power supply cable (Product Code: 467305.081) is a heavy-duty electrical wiring component engineered to establish a secure, stable, and shielded connection between the tractor’s battery and the Bravo or Delta series on-board regulation computers. Developed to support the electrical current demands generated by motorized section valves and inline monitoring sensors, this cable delivers perfect voltage continuity, isolating monitoring consoles from voltage spikes and micro-interruptions during intensive open-field spraying applications.

Design Details and Electrical Safety Architecture

The functional efficiency and metering precision of an electronic crop protection system depend directly upon the stability of its power intake source. This original Arag power harness is manufactured with high-gauge electrolytic copper cores, calculated specifically to eliminate voltage drops across the circuit, even when multiple boom section valves draw maximum inrush current during simultaneous opening or closing cycles. The power line features built-in overload and short-circuit protection via a weather-sealed blade fuse holder located near the battery terminal clamps to protect the precision logic boards inside the cab display console. The heavy-duty coupling plugs are injection-molded for advanced thermomechanical sealing, while the battery-side terminal rings are pre-insulated to counteract galvanic corrosion caused by battery acid vapors. With a 3-meter linear layout, the cable provides an optimal length for clean routing from the engine bay, through structural firewall grommets, straight to the monitor mounting bracket inside the operator cab.

Technical Specifications

Installation Guidelines and Fleet Maintenance

• Direct Battery Binding: Always secure the connection terminals straight to the primary tractor battery posts to bypass electromagnetic noise generated by other electronic subsystems wired into the vehicle's fuse block.
• Secure Cable Management: Fasten the harness along the machine's structural panels using heavy-duty cable ties, ensuring it completely bypasses high-temperature manifold areas or moving mechanical linkages.
• Terminal Contact Inspection: Periodically verify the integrity of the in-line fuse element and ensure connection plugs remain clean and free from moisture to rule out contact resistance drop-offs on the Bravo controller display.
