Arag Inductive Proximity Speed Sensor with Cable (5 m) - Code 467100.086

The professional-grade Arag inductive proximity sensor (Product Code: 467100.086) is a high-precision electronic measurement device engineered to track travel-speed velocity constants and rotational RPM parameters across mechanical components on agricultural machinery. Installed adjacent to wheel hubs, cardan shafts, or powertrain drives, this sensor registers the movement of ferrous metallic targets without physical contact, transmitting clean electrical pulse frequencies to Bravo and Delta master spray computers to execute precise proportional dosage control.

Design Details and Electronic Line Monitoring

This tachometric sensor stands out for its exceptional magnetic loop reliability and reading stability, operating within a calibrated proximity scanning threshold of 2 to 8 mm. Machine operators can instantly verify mechanical sensor alignment and pulse frequency capture via an integrated diagnostic status LED positioned on the rear face of the sensor housing, which illuminates with each validated target passage to simplify workshop setup. The cylindrical outer body features full structural threading to facilitate micrometric air-gap adjustments using double locking nuts and complies with heavy waterproof sealing standards to withstand mud, dust, and aggressive high-pressure pressure washing. Supplied with a robust 5-meter internal shielded hookup cable, the harness ensures easy routing across structural chassis articulation joints without experiencing mechanical strain or electromagnetic interference (EMI) from the vehicle power lines.

Technical Specifications

Installation Guidelines and Fleet Maintenance

• Air-Gap Calibration: Anchor the sensor barrel ensuring the clearance window between the scanning head and the ferrous target bolt remains strictly within the 2-8 mm scale to prevent signal dropouts or mechanical impact damage.
• Telemetry Verification: Monitor the rear diagnostic LED activity during manual rotation of the target assembly to guarantee that index pulses register completely before commencing field applications.
• 5 m Harness Management: Route the signal line along the implement frame rails using protective conduit around pivot clusters, securing the cable tightly to eliminate hazards from field trash or crop residues.
