BLUELINE 12216709 PTO Shaft B4 Disc Clutch

12216709 BLUELINE PTO Shaft Series B4 Lz 740mm with Friction Disc Clutch 1500Nm

Name: 12216709 BLUELINE PTO Shaft Series B4 Lz 740mm with Friction Disc Clutch 1500Nm
SKU: 12216709
Price: 199 EUR
Availability: InStock

Brand : Blueline

Reference : 12216709

BLUELINE B4 PTO Drive Shaft with Friction Clutch - L 740mm (Code 12216709)

Hurry! only 3 items left in stock.

€199.00

Tax included

Quantity

Ready for delivery

Add to Compare

Add to Wishlist

Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

Guarantee safe checkout

The BLUELINE B4 Series drive shaft (740 mm) is a professional transmission solution equipped with a Friction Disk Clutch. Rated at 1500 Nm, this safety device protects both the tractor and the implement by slipping during torque peaks, preventing mechanical failure while allowing work to resume instantly. Featuring the Italian System (triangular profile) and 27 mm cross kits, it is highly recommended for medium-duty rotary tillers, flail mowers, and mist blowers.

Technical Specifications

Part Number: 12216709

Series: B4

Total Length (Lz): 740 mm

Profile A (Tractor Side): 1 3/8" 6 Splines (Push-button)

Profile B (Implement Side): 1 3/8" 6 Splines (Locking bolt)

Cross Kit Dimension: 27 x 74.6 mm

Safety Type: Friction Disk Clutch

Tube Profile: Italian System (Triangular)

Coupling: P6/P5

Performance Data

Slipping Torque: 1500 Nm

Benefit: Continuous protection without the need to replace components after an overload event.

Operating instructions are included. To maintain performance, inspect friction disks regularly. If the shaft is stored for long periods, it is advised to loosen the clutch springs and perform a brief slip test to prevent the disks from seizing.
