Hydraulic Top Link Cylinder for Fiat Serie Oro 300 & Landini Tractors Part Number 50646
The heavy-duty hydraulic top link cylinder (code 50646) is engineered for agricultural tractor 3-point hitches, tailor-made for vintage and compact utility tractor applications. It features a minimum length of 410 mm, a stroke of 143 mm, a 60 mm bore (cylinder diameter), a 30 mm rod diameter, and a net weight of 6 kg. Both the rod end and the cylinder base end come equipped with a Ø 19.3 mm ball joint. Complete with a 3/8" dual pilot check valve, it is perfectly adaptable to Fiat Serie Oro 300 tractors as well as Landini R3200 and 3000R (First Series) models.
Read more ↓Fits
Sconto extra riservato ai clienti registrati
Accedi per sbloccare il codicePrezzo finale con coupon: €161.70
Description
The heavy-duty hydraulic top link cylinder (code 50646) is engineered for agricultural tractor 3-point hitches, tailor-made for vintage and compact utility tractor applications. It features a minimum length of 410 mm, a stroke of 143 mm, a 60 mm bore (cylinder diameter), a 30 mm rod diameter, and a net weight of 6 kg. Both the rod end and the cylinder base end come equipped with a Ø 19.3 mm ball joint. Complete with a 3/8" dual pilot check valve, it is perfectly adaptable to Fiat Serie Oro 300 tractors as well as Landini R3200 and 3000R (First Series) models.
Compatibility
| Costruttore | Modelli Compatibili |
| FIAT | SERIE ORO: 300 |
| LANDINI | R3200PRIMA SERIE: 3000R |
Model not listed? Message us on WhatsApp.
Specifications
| Tipologia Componente | Cilindro terzo punto idraulico per sollevatore agricolo |
|---|---|
| Lunghezza Minima (Chiuso) | 410 mm |
| Corsa del Cilindro | 143 mm |
| Alesaggio Interno (D) | 60 mm |
| Diametro dello Stelo (d) | 30 mm |
| Terminale dello Stelo (F) | Snodo sferico (Rotula) Ø 19.3 mm |
| Terminale del Cilindro (P) | Snodo sferico (Rotula) Ø 19.3 mm |
| Dimensione Attacchi Valvola | Filettatura 3/8" (Valvola di blocco a doppio effetto integrata) |
| Peso Netto Componente | 6 kg |
| Codice Articolo Interno | 50646 |
