GRAMMER Primo M (MSG65/521)

Product Description

The **GRAMMER Primo M** is a mechanical suspension seat designed for maximum operator comfort and safety. Ideal for forklifts and industrial vehicles, it offers a wide weight adjustment range (from 50 to 170 kg) and a longitudinal adjustment of 210 mm, ensuring an ergonomic and stable seating position. The seat also complies with the strict FEM 4.002 standard, providing proven reliability in demanding work environments.

Technical Specifications

• Product Code: g1293486
• Model: MSG65/521
• Suspension: Mechanical
• Suspension Travel: 60 mm
• Weight Adjustment: 50 - 170 kg (mechanical)
• Longitudinal Adjustment: 210 mm
• Seat Width: 480 mm
• Seat Cushion Width: 470 mm
• Backrest Tilt Adjustment: Yes
• Lumbar Support: Mechanical
• Upholstery Material: Fabric
• Overall Dimensions: Length 537 mm, Height 558 - 715 mm
• Track Width: 330 mm

Optional Accessories

The following accessories are not included as standard and can be added based on your needs:

• Seat switch
• Joystick Console
• Safety belt system
• Armrest
• Headrest

Note: This model does not include seat heating, lateral suspension, or swivel functionality.
