GRAMMER Primo XM Plus (MSG65/2731)

Product Description

The GRAMMER Primo XM Plus seat is a robust and comfortable solution, designed for earth-moving machines, agricultural loaders, and forklifts. Its low-profile mechanical suspension, with 80 mm of travel, ensures effective vibration dampening. The quick and easy step-by-step weight adjustment and integrated safety features, such as the seat switch and 2-point belt, provide a secure and ergonomic seating position in any work environment.

Technical Specifications

• Product Code: g1451073
• Model: MSG65/2731
• Suspension: Mechanical
• Suspension Travel: 80 mm
• Weight Adjustment: 45 - 170 kg (mechanical, step-by-step)
• Longitudinal Adjustment: 210 mm
• Seat Width: 570 mm
• Seat Cushion Width: 520 mm
• Lumbar Support: Mechanical
• Backrest Tilt Adjustment: Yes
• Upholstery Material: Fabric / Black Synthetic Leather
• Overall Dimensions: Length 668 mm, Height 622 mm
• Track Width: 328 mm
• Seat Switch: Included
• Safety Belt System: Included (2-point belt, Duo Sensitive automatic with winder)
• Compatible with: Earth-moving machines, agricultural loaders, forklifts

Optional Accessories

The following accessories are not included as standard and can be added based on your needs:

• Longitudinal horizontal suspension
• Seat heating
• Armrest
• Headrest
