GRANIT Z50 2-Lever Valve with Pressure Beyond

GRANIT Z50 Control Valve 2-Bank Double Acting Spring Return with Carry-Over Code 87001367

Granit
87001367

GRANIT Z50 valve, 2x double acting with pressure beyond/carry-over function. 40 l/min flow rate, 250 bar PN. P-T 1/2" BSP, A-B 3/8" BSP. Code 87001367.

Hurry! only 2 items left in stock.
€194.90
Tax included
Quantity

Last items in stock
Add to Compare
Add to Wishlist
  Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

  Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

  Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

GRANIT Z50 series monobloc control valve, 2-lever configuration for double-acting functions. Special version equipped for Carry-Over (pressure beyond) connection, ideal for adding additional hydraulic services in series.
Product Description
The GRANIT Z50 distributor (Part No. 87001367) is a versatile component for controlling two double-acting cylinders. Unlike standard models, this reference (02Z50 1A1A1 GKZ1C) is designed for power beyond applications. This feature allows hydraulic pressure to be carried over to a second valve block installed downstream, maintaining the efficiency of the primary hydraulic circuit. In neutral position, ports A and B remain closed, locking the load in place. Built from high-strength monobloc cast iron, the valve integrates an adjustable relief valve (120-250 bar) and manages a flow rate of 40 l/min, making it perfect for front loaders or backhoes requiring future hydraulic system expansions.
Technical Data & Dimensions
Part Number 87001367
Original Reference 02Z50 1A1A1 GKZ1C
Nominal Flow Rate 40 l/min
Max Pressure (PN) 250 bar
Version Carry-Over (Pressure Beyond)
Ports P - T (BSP) G 1/2"
Ports A - B (BSP) G 3/8"
Dimensions (A-B-C-D) 60 - 80 - 129 - 97 mm
: 87001367
