GRANIT Z50 Control Valve 2-Bank Double Acting Spring Return Code 87000921

Name: GRANIT Z50 Control Valve 2-Bank Double Acting Spring Return Code 87000921
SKU: 87000921
Price: 99 EUR
Availability: InStock

Brand : Granit

Reference : 87000921

GRANIT Z50 valve, 2x double acting (A-B closed), spring return. 40 l/min flow rate, 250 bar PN. P-T 1/2" BSP, A-B 3/8" BSP. Code 87000921.

Hurry! only 3 items left in stock.

€99.00

Tax included

Quantity

Ready for delivery

Add to Compare

Add to Wishlist

Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

Guarantee safe checkout

GRANIT Z50 series monobloc control valve, 2-lever configuration for double-acting cylinders. Designed for smooth and precise hydraulic flow control up to 40 l/min, featuring a compact and robust design suitable for heavy-duty working conditions.

Product Description

The GRANIT Z50 distributor (Part No. 87000921) is a 4/3-way valve with spring return to center, configured to manage two independent double-acting functions. In the neutral position, ports A and B are closed, ensuring the load is held in place. The valve features an adjustable pressure relief valve (preset between 120 and 250 bar) to protect the system from overpressure. Thanks to its high-resistance cast iron monobloc structure, it offers low pressure drops and excellent durability. The 1/2" BSP inlet and outlet ports ensure optimal discharge capacity, while the 3/8" BSP working ports simplify installation on standard hydraulic lines.

Technical Data & Dimensions

Part Number	87000921
Original Reference	02Z50 1 A1A1 GKZ1
Nominal Flow Rate	40 l/min
Max Pressure (PN)	250 bar
Configuration	2 Levers - Double Acting (A-B closed)
Ports P - T (Inlet/Outlet)	G 1/2" BSP
Ports A - B (Working)	G 3/8" BSP
Dimensions (A-B-C-D)	60 - 80 - 129 - 97 mm
