GRANIT Z50 Control Valve 2-Bank Double Acting with Joystick and Float Position Code 87000927

GRANIT Z50 series monobloc control valve with cross-lever (Joystick) control. It integrates a special float effect on the first section, allowing ergonomic and simultaneous control of two double-acting functions, ideal for agricultural loaders.

Product Description

The GRANIT Z50 distributor (Part No. 87000927) represents the ergonomic evolution for hydraulic system control. Thanks to the cross-lever (JS), the operator can manage both spools simultaneously with a single hand movement (forward/backward and left/right). The first section is equipped with a special fourth position, the float effect (K16): in this mode, the cylinder chambers communicate with the return line, allowing equipment (such as a blade or bucket) to follow ground irregularities freely. Both functions are double-acting with spring return to neutral. The high-strength cast iron monobloc structure includes an adjustable safety valve between 120 and 250 bar, ensuring high performance and constant reliability with flow rates up to 40 l/min.

Technical Data & Dimensions
