GRANIT Z50 Control Valve 2-Bank Double Acting Spring Return and Detented Float Position Code 87000980

GRANIT Z50 series 2-lever monobloc control valve. Special version featuring one standard double-acting section and one section with a float position in neutral and mechanical detent in all positions, ideal for controlling motors or continuous flow services.

Product Description

The GRANIT Z50 distributor (Part No. 87000980) is configured for advanced hydraulic applications. The first section (A1) is a classic double-acting spool with spring return to neutral. The second section (D8) is the distinguishing feature: it provides a float position directly in the neutral position (ports A and B connected to the tank), allowing the implement to move freely without pressure when the lever is not actuated. Furthermore, this section is equipped with a mechanical detent system that holds the lever in every position set by the operator, without an automatic spring return. Built from high-strength monobloc cast iron, it includes an adjustable relief valve (120-250 bar) and handles flow rates up to 40 l/min, ensuring reliability and precision for agricultural and industrial actuator control.

Technical Data & Dimensions
