BLUELINE 3771210B81011 PTO Shaft Series B8 1210mm

3771210B81011 BLUELINE PTO Drive Shaft Series B8 Lz 1210mm for Tractors up to 90HP

Reference : 3771210B81011

BLUELINE B8 Series PTO Drive Shaft - L 1210mm (Code 3771210B81011)

Hurry! only 2 items left in stock.

€249.90

Tax included

Quantity

Last 2 items

Add to Compare

Add to Wishlist

Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

Guarantee safe checkout

The BLUELINE B8 Series drive shaft (1210 mm) is an industrial-grade transmission component engineered for high-power agricultural tractors and large-scale machinery requiring extended reach. Featuring massive 34.9x106 mm cross kits and a reinforced "Italian System" telescopic profile, this model is built to handle extreme nominal torque (1165 Nm at 540 rpm), providing maximum durability for the most demanding intensive field operations.

Technical Specifications

Part Number: 3771210B81011

Series: B8 (Standard Version)

Total Length (Lz): 1210 mm

Profile A (Tractor Side): 1 3/8" 6 Splines

Profile B (Implement Side): 1 3/8" 6 Splines

Cross Kit Dim. (Profile A/B): 34.9 x 106 mm

Locking System: Push-button / Push-button (P10/P11 Coupling)

Tube Profile: Italian System

Performance Data

Power at 540 rpm: Up to 90 HP (66 kW)

Power at 1000 rpm: Up to 136 HP (100 kW)

Nominal Torque (540 rpm): 1165 Nm

Nominal Torque (1000 rpm): 955 Nm

Operating instructions are included. For B8 series shafts of this length, always ensure that safety chains are properly attached and grease the oversized universal joints every 8 working hours to ensure peak performance under high-stress conditions.
