BLUELINE 37756023934 PTO Shaft Series F23 560mm

37756023934 BLUELINE PTO Drive Shaft Series F23 Lz 560mm for Tractors up to 35HP

star star star star star_border
Blueline
37756023934

BLUELINE F23 Series PTO Drive Shaft - L 560mm (Code 37756023934)

Hurry! only 3 items left in stock.
€119.90
Tax included
COUPON
- € 2,40
Final price: € 117,50
Quantity

Last 3 items
Add to Compare
Add to Wishlist
Security Policy
Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy
Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments
Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

The BLUELINE F23 Series drive shaft (560 mm) is an ultra-compact, high-torque transmission component. Featuring reinforced 27 x 74.6 mm universal joints and a 460 Nm nominal torque rating, it is designed for demanding implements where space is limited. The Lemon Profile provides excellent structural integrity for machinery such as high-pressure sprayers, compact rotary hoes, and specialized orchard equipment.

Technical Specifications

Part Number: 37756023934

Series: F23 (Standard Version)

Total Length (Lz): 560 mm

Profile A (Tractor Side): 1 3/8" 6 Splines

Profile B (Implement Side): 1 3/8" 6 Splines

Cross Kit Dim. (Profile A/B): 27 x 74.6 mm

Locking System: Push-button / Push-button (G3/G4 Coupling)

Tube Profile: Lemon Profile

Performance Data

Power at 540 rpm: Up to 35 HP (26 kW)

Power at 1000 rpm: Up to 53 HP (39 kW)

Nominal Torque (540 rpm): 460 Nm

Nominal Torque (1000 rpm): 370 Nm

Operating instructions are included. For short-length shafts, always verify that the telescopic tubes have enough travel to accommodate the implement's range of motion without bottoming out.
