BLUELINE 377377434 PTO Shaft Series F25 1210mm

377377434 BLUELINE PTO Drive Shaft Series F25 Lz 1210mm for Tractors up to 90HP

Reference : 377377434

BLUELINE F25 Series PTO Drive Shaft - L 1210mm (Code 377377434)

Hurry! only 2 items left in stock.

€319.90

Tax included

Quantity

Last 2 items

Add to Compare

Add to Wishlist

Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

Guarantee safe checkout

The BLUELINE F25 Series drive shaft (1210 mm) is a high-capacity transmission component designed for professional-grade agricultural implements. Utilizing the advanced Star Profile for maximum torque distribution and massive 36 x 89 mm cross kits, it delivers a nominal torque of 1165 Nm. This extended-reach model is ideal for heavy rotary harrows, large-scale diet feeders, and trailed combined seed drills requiring reliable power from 100+ HP tractors.

Technical Specifications

Part Number: 377377434

Series: F25 (Standard Version)

Total Length (Lz): 1210 mm

Profile A (Tractor Side): 1 3/8" 6 Splines

Profile B (Implement Side): 1 3/8" 6 Splines

Cross Kit Dimension (A/B): 36 x 89 mm

Locking System: Push-button / Push-button (G7/G8 Coupling)

Tube Profile: Star Profile

Performance Data

Power at 540 rpm: Up to 90 HP (66 kW)

Power at 1000 rpm: Up to 140 HP (102 kW)

Nominal Torque (540 rpm): 1165 Nm

Nominal Torque (1000 rpm): 970 Nm

Operating instructions are included. For high-torque 1210 mm shafts, ensure regular greasing of the 36 mm universal joints and check that telescopic overlap is maintained throughout the machine's range of motion to prevent structural failure.
