BLUELINE 377377250 PTO Shaft Series F23 1210mm

377377250 BLUELINE PTO Shaft Series F23 Lz 1210mm Yoke Ø 30mm and 1 3/8" Z6

star star star star star_border
Blueline
377377250

BLUELINE F23 Series PTO Drive Shaft - L 1210mm (Code 377377250)

Hurry! only 3 items left in stock.
€169.90
Tax included
COUPON
- € 3,40
Final price: € 166,50
Quantity

Last 3 items
Add to Compare
Add to Wishlist
Security Policy
Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy
Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments
Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

The BLUELINE F23 Series drive shaft (1210 mm) is a heavy-duty transmission component designed for professional agricultural machinery. It features a specialized 30 mm bore hub yoke (Profile A) with a clamping bolt and 8 mm keyway for secure, permanent mounting. Equipped with reinforced 27 x 74.6 mm cross kits and the reliable Lemon Profile, it delivers a nominal torque of 460 Nm over extended reaches.

Technical Specifications

Part Number: 377377250

Series: F23 (Standard Version)

Total Length (Lz): 1210 mm

Profile A (Implement Side): Ø 30 mm, hub with clamping bolt and 8 mm keyway

Profile B (Tractor Side): 1 3/8" 6 Splines

Cross Kit Dim. (Profile A/B): 27 x 74.6 mm

Locking System: Push-button / Clamping bolt (G3/G4 Coupling)

Tube Profile: Lemon Profile

Performance Data

Power at 540 rpm: Up to 35 HP (26 kW)

Power at 1000 rpm: Up to 53 HP (39 kW)

Nominal Torque (540 rpm): 460 Nm

Nominal Torque (1000 rpm): 370 Nm

Operating instructions are included. For the 30 mm hub connection, verify that the keyway is properly aligned and the clamping bolt is tightened according to technical safety standards before operation.

: 377377250
Hurry! only 3 items left in stock.

Fast and safe shipping: each order is carefully packaged to ensure that the product arrives intact and in perfect condition.

We work with reliable couriers to offer an efficient, traceable and punctual service.

You will receive a link to follow the shipment at every stage, until delivery.

We use quality protective materials and, where possible, eco-friendly packaging.

Our priority is that your purchase arrives without surprises, ready to use.
