BLUELINE 377056024956 PTO Shaft Series F24 560mm

377056024956 BLUELINE PTO Drive Shaft Series F24 Lz 560mm for Tractors up to 53HP

Blueline
377056024956

BLUELINE F24 Series PTO Drive Shaft - L 560mm (Code 377056024956)

Hurry! only 3 items left in stock.
€185.00
Tax included
Quantity

Ready for delivery
Add to Compare
Add to Wishlist
  Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

  Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

  Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

The BLUELINE F24 Series drive shaft (560 mm) is an ultra-compact, high-power transmission component. Engineered for high-load agricultural implements, it features robust 32 x 76 mm universal joints and G5/G6 coupling. Delivering a nominal torque of 690 Nm, the Lemon Profile tubes ensure structural integrity for equipment like heavy-duty compact rotary tillers and forestry mulchers where space is limited.

Technical Specifications

Part Number: 377056024956

Series: F24 (Standard Version)

Total Length (Lz): 560 mm

Profile A (Tractor Side): 1 3/8" 6 Splines

Profile B (Implement Side): 1 3/8" 6 Splines

Cross Kit Dim. (Profile A/B): 32 x 76 mm

Locking System: Push-button / Push-button (G5/G6 Coupling)

Tube Profile: Lemon Profile

Performance Data

Power at 540 rpm: Up to 53 HP (39 kW)

Power at 1000 rpm: Up to 83 HP (61 kW)

Nominal Torque (540 rpm): 690 Nm

Nominal Torque (1000 rpm): 580 Nm

Operating instructions are included. For F24 series shafts, regular greasing of the 32 mm cross kits is mandatory to maintain high-torque performance and durability.
