BLUELINE 3770121024956 PTO Shaft Series F24 1210mm

3770121024956 BLUELINE PTO Drive Shaft Series F24 Lz 1210mm for Tractors up to 53HP

star star star star star_border
Blueline
3770121024956

BLUELINE F24 Series PTO Drive Shaft - L 1210mm (Code 3770121024956)

Hurry! only 2 items left in stock.
€179.90
Tax included
COUPON
- € 3,60
Final price: € 176,30
Quantity

Last 2 items
Add to Compare
Add to Wishlist
Security Policy
Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy
Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments
Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

The BLUELINE F24 Series drive shaft (1210 mm) is a professional-grade transmission component built for high-power agricultural implements. Featuring heavy-duty 32 x 76 mm universal joints and G5/G6 coupling, it is designed to handle a nominal torque of 690 Nm. The Lemon Profile telescopic tubes provide superior strength for high-torque applications such as heavy rotary harrows, large flail mowers, and diet feeders.

Technical Specifications

Part Number: 3770121024956

Series: F24 (Standard Version)

Total Length (Lz): 1210 mm

Profile A (Tractor Side): 1 3/8" 6 Splines

Profile B (Implement Side): 1 3/8" 6 Splines

Cross Kit Dim. (Profile A/B): 32 x 76 mm

Locking System: Push-button / Push-button (G5/G6 Coupling)

Tube Profile: Lemon Profile

Performance Data

Power at 540 rpm: Up to 53 HP (39 kW)

Power at 1000 rpm: Up to 83 HP (61 kW)

Nominal Torque (540 rpm): 690 Nm

Nominal Torque (1000 rpm): 580 Nm

Operating instructions are included. For high-torque F24 shafts, always ensure proper telescopic overlap and that the safety chains are secured to rigid mounting points to prevent disconnection or accidents under heavy load.

: 3770121024956
Hurry! only 2 items left in stock.

Fast and safe shipping: each order is carefully packaged to ensure that the product arrives intact and in perfect condition.

We work with reliable couriers to offer an efficient, traceable and punctual service.

You will receive a link to follow the shipment at every stage, until delivery.

We use quality protective materials and, where possible, eco-friendly packaging.

Our priority is that your purchase arrives without surprises, ready to use.
