Eye/Hook Hydraulic Top Link

Speed up your field setup operations and adjust your implement alignment directly from the cab with our range of hydraulic top links in eye/quick-hitch hook configuration. These hydraulic cylinders feature a traditional spherical ball joint (eye) on the tractor side and an automatic quick-release hook on the implement side. This combination pairs the excellent multi-directional oscillation of the ball joint with the extreme practicality of the automatic hook, allowing you to couple and uncouple operating machinery in seconds and completely on your own. Built with high-strength steel barrels, thick chrome-plated rods, and integrated double-acting pilot-operated check valves, they guarantee micrometric position holding under heavy stress and maximum safety against structural failure. They are the ideal solution for managing heavy implements like plows, tillers, and shredders, reducing physical strain and optimizing working times.

Eye to Quick-Hitch Hook Hydraulic Top Links | Tractor

Active filters

Aftermarket

Hydraulic Top Link Cylinder Cat. 2 for Landini Mistral & New Holland T3000 Tractors Part Number 50957

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50957) is engineered for agricultural tractor 3-point hitches, tailor-made for compact tractor applications. It features a minimum length of 470 mm, a stroke of 173 mm, a 50 mm bore (cylinder diameter), a 30 mm rod diameter, and a net weight of 8.74 kg. The rod end comes equipped with a Cat. 2 National quick-release hook, while the cylinder base end features a Ø 19.3 mm ball joint. Complete with a 3/8" dual pilot check valve, it is perfectly adaptable to Landini Mistral series tractors manufactured from 1998 to 2004 (models 40, 45, 50, 55) and New Holland T 3000 series tractors (models T 3010, T 3020, T 3030, T 3040).

Latest 3 articles
€230.00

Aftermarket

Hydraulic Top Link Cylinder Cat. 2 for Same Solaris & New Holland TCE Tractors Part Number 50936

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50936) is engineered for agricultural tractor 3-point hitches, specifically designed to fit compact and orchard tractor models. It features a minimum length of 470 mm, a stroke of 154 mm, a 60 mm bore (cylinder diameter), a 30 mm rod diameter, and a net weight of 9.3 kg. The rod end comes equipped with a Cat. 2 National quick-release hook, while the cylinder base end features a Ø 19.3 mm ball joint. Complete with a 3/8" dual pilot check valve, it is custom-designed for New Holland TCE series (TCE 40, TCE 45, TCE 50, TCE 55), Same Solaris (Solaris 25, Solaris 35, Solaris 45), and Lamborghini (R 130, R 140) tractors.

Processing in approximately 2-3 working days
€255.00

Aftermarket

Hydraulic Top Link Cylinder Cat. 2 for Landini Globus Tractors Part Number 50956

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50956) is engineered for agricultural tractor 3-point hitches, specifically adaptable to Landini tractors. It features a minimum length of 550 mm, a stroke of 230 mm, a 60 mm bore (cylinder diameter), a 30 mm rod diameter, and a net weight of 9.6 kg. The rod end comes equipped with a Cat. 2 National quick-release hook, while the cylinder base end features a Ø 19.3 mm ball joint. Complete with a 3/8" dual pilot check valve, it is custom-designed for Landini Globus series tractors manufactured between 1998 and 2004 (models Globus 55, Globus 65, Globus 75, Globus 80).

Latest 1 articles
€265.00

Aftermarket

Hydraulic Top Link Cylinder 510mm Cat. 2 with Quick Release Hook Part Number 50875

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50875) is engineered for agricultural tractor 3-point hitches. It features a minimum length of 510 mm, a stroke of 180 mm, a 60 mm bore (cylinder diameter), and a 30 mm rod diameter. It comes equipped with a Cat. 2 National quick-release hook on the rod end, a Ø 25.4 mm ball joint on the cylinder base end, and a 3/8" dual pilot check valve.

Latest 2 articles
€265.00

Aftermarket

Hydraulic Top Link Cylinder 560mm Cat. 2 with Quick Release Hook Part Number 50876

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50876) is engineered for agricultural tractor 3-point hitches. It features a minimum length of 560 mm, a stroke of 230 mm, a 60 mm bore (cylinder diameter), and a 30 mm rod diameter. It comes equipped with a Cat. 2 National quick-release hook on the rod end, a Ø 25.4 mm ball joint on the cylinder base end, and a 3/8" dual pilot check valve.

Latest 2 articles
€269.00

Aftermarket

Hydraulic Top Link Cylinder Cat. 2 for Lamborghini Tractors Part Number 50879

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50879) is engineered for agricultural tractor 3-point hitches, specifically adaptable to Lamborghini tractors (specifically models 760 DTR and 256 DT). It features a minimum length of 500 mm, a stroke of 170 mm, a 70 mm bore (cylinder diameter), a 35 mm rod diameter, and a net weight of 11 kg. It comes equipped with a Cat. 2 National quick-release hook on the rod end, a Ø 25.4 mm ball joint on the cylinder base end, and a 3/8" dual pilot check valve.

High Availability
€279.00

Aftermarket

Hydraulic Top Link Cylinder for Goldoni Tractors Cat. 2 National Quick Hook Part Number 51252

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 51252) is engineered for agricultural tractor 3-point hitches, custom-designed to fit Goldoni tractors. It features a minimum length of 600 mm, a stroke of 238 mm, a 60 mm bore (cylinder diameter), a 30 mm rod diameter, and a net weight of 11.5 kg. The rod end is equipped with a Cat. 2 National quick-release hook, while the cylinder base end features a Ø 19.3 mm ball joint. Complete with a 3/8" dual pilot check valve, it is perfectly adaptable to Goldoni 3000 Series (3050, 3070), Compact series (614D, 654, 664, 774), Star Quadrifoglio (4000 Q), and Star series (50, 70, 75) tractors.

Latest 1 articles
€280.00

Aftermarket

Hydraulic Top Link Cylinder Cat. 2 for Fiat, New Holland, Landini & Same Tractors Part Number 50790

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50790) is engineered for agricultural tractor 3-point hitches. It features a minimum length of 620 mm, a stroke of 290 mm, a 70 mm bore (cylinder diameter), a 35 mm rod diameter, and a net weight of 13.43 kg. It comes equipped with a Cat. 2 National quick-release hook on the rod end, a Ø 25.4 mm ball joint on the cylinder base end, and a 3/8" dual pilot check valve. This highly versatile cylinder is adaptable to numerous tractor models, including Fiat (500 & 80 Series), New Holland (L, TL, TLF Series), Landini (Atlas, Ghibli, and Trekker crawler series), and Same Explorer.

Latest 4 articles
€290.00

Aftermarket

Hydraulic Top Link Cylinder Cat. 2 for New Holland TN, Claas & Zetor Tractors Part Number 50755

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50755) is engineered for agricultural tractor 3-point hitches. It features a minimum length of 580 mm, a stroke of 250 mm, a 70 mm bore (cylinder diameter), a 35 mm rod diameter, and a net weight of 12.67 kg. It comes equipped with a Cat. 2 National quick-release hook on the rod end, a Ø 25.4 mm ball joint on the cylinder base end, and a 3/8" dual pilot check valve. This versatile cylinder is specifically adaptable to New Holland TN series (TN D, TN F, TN N, TN V), Claas/Renault Elios series (210, 220, 230, 240 Stage 3B), and Zetor tractors (Proxima and Proxima Plus series).

High Availability
€290.00

Aftermarket

Hydraulic Top Link Cylinder Cat. 2 for John Deere Tractors Part Number 50606

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50606) is engineered for agricultural tractor 3-point hitches. It features a minimum length of 550 mm, a stroke of 215 mm, a 70 mm bore (cylinder diameter), a 35 mm rod diameter, and a net weight of 12.2 kg. It comes equipped with a Cat. 2 National quick-release hook on the rod end, a Ø 25.4 mm ball joint on the cylinder base end, and a 3/8" dual pilot check valve. This cylinder is specifically adaptable to European John Deere tractors from the 5020 Series (5820), 6000 Series (6100, 6200, 6300), and 6010 Series (6110, 6210, 6310).

High Availability
€290.00

Aftermarket

Hydraulic Top Link Cylinder for Goldoni Tractors Cat. 2 Walterscheid Hook Part Number 50890

star star star star star_border

The specialized hydraulic top link cylinder (code 50890, adaptable to OEM part numbers 00036490 and 00062190) is custom-engineered for Goldoni tractors. It features a minimum length of 600 mm, a stroke of 238 mm, a 60 mm bore, and a 30 mm rod diameter. The rod end is equipped with a premium Cat. 2 Walterscheid quick-release hook, while the cylinder base end features a Ø 19.3 mm ball joint. Complete with a 3/8" dual pilot check valve, it perfectly fits Goldoni Compact series (614D, 654, 664, 774), Star Quadrifoglio (4000 Q), and Star series (50, 70, 75) tractors.

Latest 3 articles
€319.00

Aftermarket

Hydraulic Top Link Cylinder Cat. 2 for Fiat Crawler Tractors Part Number 50934

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50934) is engineered for agricultural tractor 3-point hitches, specifically adaptable to Fiat Crawler (Cingoli) tractors. It features a minimum length of 500 mm, a stroke of 170 mm, a 70 mm bore (cylinder diameter), a 35 mm rod diameter, and a net weight of 10.2 kg. It comes equipped with a Cat. 2 National quick-release hook on the rod end, a Ø 19.3 mm ball joint on the cylinder base end, and a 3/8" dual pilot check valve. This model perfectly fits Fiat crawler models from the 85 Series (Frutteto, Vigneto, Montagna, ranging from 55-85 to 88-85) and the 75 Series (60-75, 70-75, 80-75).

Processing in approximately 2-3 working days
€335.00

Aftermarket

Hydraulic Top Link Cylinder 630mm Cat. 2 with Quick Release Hook Part Number 50877

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50877) is engineered for agricultural tractor 3-point hitches. It features a minimum length of 630 mm, a stroke of 295 mm, a 60 mm bore (cylinder diameter), and a 30 mm rod diameter. It comes equipped with a Cat. 2 National quick-release hook on the rod end, a Ø 25.4 mm ball joint on the cylinder base end, and a 3/8" dual pilot check valve.

Latest 1 articles
€335.00

Aftermarket

Hydraulic Top Link Cylinder Cat. 2 for Steyr M975 Tractors Part Number 50968

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50968) is engineered for agricultural tractor 3-point hitches, specifically adaptable to Steyr tractors from the M Series (specifically the M975 model). It features a minimum length of 520 mm, a stroke of 220 mm, a 70 mm bore (cylinder diameter), a 35 mm rod diameter, and a net weight of 11.3 kg. It comes equipped with a Cat. 2 National quick-release hook on the rod end, a Ø 25.4 mm ball joint on the cylinder base end, and a 3/8" dual pilot check valve.

Processing in approximately 2-3 working days
€339.00

Aftermarket

Hydraulic Top Link Cylinder 740mm Cat. 2 with Quick Release Hook Part Number 50880

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50880) is engineered for agricultural tractor 3-point hitches. It features a minimum length of 740 mm, an extended stroke of 400 mm, a 70 mm bore (cylinder diameter), and a 35 mm rod diameter. It comes equipped with a Cat. 2 National quick-release hook on the rod end, a Ø 25.4 mm ball joint on the cylinder base end, and a 3/8" dual pilot check valve.

Latest 3 articles
€349.00

Aftermarket

Hydraulic Top Link Cylinder for New Holland Tractors Cat. 2 Quick Hook Part Number 50937

star star star star star_border

The heavy-duty hydraulic top link cylinder (code 50937) is engineered for agricultural tractor 3-point hitches, specifically adaptable to New Holland tractors from the TD D Series (models TD 55D, TD 60D, TD 65D, TD 70D, TD 75D, TD 80D, TD 85D, TD 90D, TD 95D). It features a minimum length of 700 mm, a stroke of 370 mm, a 70 mm bore, and a 35 mm rod diameter. It comes equipped with a Cat. 2 National quick-release hook on the rod end, a Ø 25.4 mm ball joint on the cylinder base end, and a 3/8" dual pilot check valve.

Latest 2 articles
€358.99
