Endurance Energy 12V 100Ah 820A EN Heavy-Duty Starter Battery for Case IH Tractors - Part Number: 5850010038
The Endurance Energy 12V 100Ah (820A EN cold cranking) heavy-duty starter battery (part number 5850010038, genuine manufacturer and Case IH OEM references GP 100 S1, GB 60044R, GB60044RBHDADAPTER, 47370942, 84602503, B512584) is an authentic OEM-grade high-capacity accumulator engineered specifically to meet the high cranking torque and continuous electrical demands of Case IH field and utility agricultural tractors. Built with advanced Calcium/Calcium (Ca/Ca) technology in standard SLI configuration, it is delivered filled, factory pre-charged, and 100% maintenance-free. Featuring standard casing dimensions of 353 x 175 x 190 mm, standard European Type 1 conical posts arranged in Layout 1 reversed polarity (positive terminal on the left – LH), a B03 hold-down base ledge, and an EN 50342 class V3 vibration resistance rating, it protects internal plate packs from mechanical fatigue during heavy draft and field operations. Backed by a 3-year warranty, it delivers direct plug-and-play fitment across Case IH tractor lines (CS series: CS 48, CS 150; Farmall A series: Farmall 85A, 95A, 105A, 115A Tier 4).
Key Features & Engineering Advantages
- High Cold Cranking Performance (820A EN): Substantial instantaneous discharge power specifically engineered to turn over 4- and 6-cylinder turbocharged and common-rail diesel engines reliably, even in harsh sub-zero winter conditions.
- Maintenance-Free Calcium/Calcium (Ca/Ca) Technology: Advanced lead-calcium grid formulation minimizes seasonal self-discharge and eliminates water consumption, ready for heavy duty straight out of the box.
- Class V3 Vibration Resistance (EN 50342 Standard): Reinforced plate anchoring and heavy-duty pocket separators deliver superior mechanical endurance against rough terrain shocks and intensive field oscillations.
- Extended 3-Year Commercial Warranty: Industrial-grade build standards and rigorous quality testing provide long operational service life and dependable long-term protection.
- Layout 1 Polarity (+ / - Positive on the Left): Standard terminal arrangement designed to align cleanly with factory battery cable runs on Case IH tractor chassis without cable tension.
- Engineered B03 Base Ledge: Molded bottom ledge profile ensures secure, rigid clamping inside tractor battery trays and chassis cradles.
Technical Specifications
| Commercial Part Number |
5850010038 |
| Manufacturer & Case IH OEM References |
GP 100 S1, GB 60044R, GB60044RBHDADAPTER, 47370942, 84602503, B512584 |
| Brand / Product Range |
Endurance Energy |
| Nominal Voltage |
12 V |
| Nominal Capacity (Ah) |
100 Ah |
| Cold Cranking Amps (CCA) |
820 A (EN rating) |
| Cell Technology |
Calcium/Calcium (Ca/Ca) – Filled, pre-charged, maintenance-free |
| Battery Classification |
SLI (Heavy Duty Agricultural / Commercial) |
| Terminal Type |
Type 1 (standard European conical posts) |
| Circuit / Polarity Layout |
Layout 1 (Positive on the left – LH) • Terminal sequence: + / - |
| Base Hold-Down Type |
B03 |
| Vibration Resistance |
Class V3 (in accordance with EN 50342) |
| Warranty Coverage |
3-Year Warranty |
| External Dimensions (L x W x H) |
353 x 175 x 190 mm |
Equipment Compatibility & Case IH Tractor Models
| Manufacturer |
Machine Series |
Supported Tractor Models |
| Case IH |
CS Series |
CS 48 (2/97–1/01), CS 150 (4/96–4/00), CS 150 (4/00–7/03) |
| Farmall A Series (Tier 4) |
Farmall 85A Tier4, Farmall 95A Tier4, Farmall 105A Tier4, Farmall 115A Tier4 |
Installation Advice & Workshop Notes: Before installation, confirm the compartment dimensions (353x175x190 mm) and verify the Layout 1 polarity scheme (positive terminal on the left). Switch off the tractor ignition and main master disconnect switch; disconnect the negative cable (-) first, then the positive cable (+). Seat the battery into the tray so that the B03 base ledges engage the tray clamps, and tighten hold-down brackets firmly to ensure full Class V3 vibration protection. Reconnect standard Type 1 posts by attaching the positive terminal (+) first and the negative terminal (-) last; do not overtighten clamp bolts and apply a thin film of technical petroleum jelly or dielectric grease to prevent corrosion. During seasonal machinery storage, disconnect leads or connect to a 12V smart maintenance charger in a dry, ventilated area.
