BLUELINE 377086024956 PTO Shaft Series F24 860mm

377086024956 BLUELINE PTO Drive Shaft Series F24 Lz 860mm for Tractors up to 53HP

Blueline
377086024956

BLUELINE F24 Series PTO Drive Shaft - L 860mm (Code 377086024956)

Hurry! only 2 items left in stock.
€149.90
Tax included
Quantity

Last items in stock
Add to Compare
Add to Wishlist
  Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

  Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

  Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

The BLUELINE F24 Series drive shaft (860 mm) is a professional transmission solution engineered for high-power agricultural implements. Featuring robust 32 x 76 mm universal joints and G5/G6 coupling, it is built to sustain a nominal torque of 690 Nm. The Lemon Profile telescopic tubes provide high torsional rigidity, making it suitable for heavy-duty rotary tillers, forestry mulchers, and large-scale sprayers.

Technical Specifications

Part Number: 377086024956

Series: F24 (Standard Version)

Total Length (Lz): 860 mm

Profile A (Tractor Side): 1 3/8" 6 Splines

Profile B (Implement Side): 1 3/8" 6 Splines

Cross Kit Dim. (Profile A/B): 32 x 76 mm

Locking System: Push-button / Push-button (G5/G6 Coupling)

Tube Profile: Lemon Profile

Performance Data

Power at 540 rpm: Up to 53 HP (39 kW)

Power at 1000 rpm: Up to 83 HP (61 kW)

Nominal Torque (540 rpm): 690 Nm

Nominal Torque (1000 rpm): 580 Nm

Operating instructions are included. For high-torque F24 applications, ensure regular lubrication of the cross kits and inspect the safety guards for wear to guarantee safe and efficient power transmission.

: 377086024956
Hurry! only 2 items left in stock.

Fast and safe shipping: each order is carefully packaged to ensure that the product arrives intact and in perfect condition.

We work with reliable couriers to offer an efficient, traceable and punctual service.

You will receive a link to follow the shipment at every stage, until delivery.

We use quality protective materials and, where possible, eco-friendly packaging.

Our priority is that your purchase arrives without surprises, ready to use.
