Stainless Steel Nozzle Holder Spray Rail 1/2" with 5 U-Clamps (120 cm) - Code 25061
The professional-grade 1/2" Stainless Steel nozzle holder spray rail (Product Code: 25061) is a heavy-duty structural and fluid-dynamic manifold segment engineered for the custom building, repair, or expansion of distribution lines on wide boom sprayers, large weeding rigs, and orchard atomizers. Supplied in a bare nozzle-free configuration, this pre-arranged steel pipeline delivers a rigid and highly durable foundation for mounting clamp-on nozzle bodies, optimizing fluid supply loops during precision farming chemical applications.
Design Details and Mounting Architecture
This pipeline segment is fully manufactured from premium industrial-grade Stainless Steel (INOX) with a 1/2" nominal bore diameter, a material selection that guarantees absolute resistance against rust, galvanic oxidation, and chemical degradation triggered by concentrated pesticides, liquid acids, or aggressive fertilizers. The manifold features an exact linear extension of 120 cm and comes factory-equipped with 5 structural U-clamps (mounting collars) positioned along the barrel. This design enables rigid mechanical binding of the steel rail onto the sprayer's structural implement chassis, dampening severe field vibrations and absorbing hydraulic shock loads stemming from line pressure shifts. The smooth inner surface of the INOX conduit maintains consistent laminar fluid flow, minimizing internal pressure drops while preventing the accumulation of chemical scaling or wettable powder residues, allowing for easy clean-water flushing procedures.
Technical Specifications
| Component Classification |
Primary fluid manifold pipeline / structural spray boom rail segment |
| Nominal Conduit Diameter |
1/2" (Half-inch gauge) |
| Manifold Longitudinal Extension |
120 cm (1.2 Meters) |
| Included U-Clamps Quantity |
5 structural chassis-mounting collar clamps |
| Output Distribution Interface |
Tailored for clamp-on nozzle assemblies, supplied clean without jets/nozzles |
| Rail Structural Material |
Stainless Steel (INOX – premium corrosion and wear defense) |
| Product Reference Code |
25061 |
Operational Guidelines and Field Assembly Advice
- Rigid Chassis Mounting: Secure the 120 cm segment onto the primary frame of the spray boom using the 5 integrated structural U-clamps. Distribute the attachment points evenly to eliminate any mechanical bending or play during rough field operations.
- Nozzle Array Customization: Since this rail is supplied bare, operators have total freedom to align single, twin, or multi-selection (trijet/quadrijet) clamp-on nozzle bodies matched for 1/2" tubing, adjusting nozzle spacing parameters across the full 1.2-meter span to meet specific swath criteria.
- Line Rinsing & Maintenance: Due to the anti-corrosive nature of Stainless Steel, the pipeline core resists crystallization and chemical binding. Running a systematic clear-water purge cycle after each treatment session washes away compound residues, protecting the seals of the attached clamp units.
