T-Frame Section Spraying Boom 3+3 Jets with Ceramic Nozzles Part 26848

star star star star star_border
26848

The T-frame section spraying boom (part 26848), engineered to replace OEM 005010, is a linear fluid distribution line designed for agricultural sprayers. Featuring a total length of 560 mm and a 3+3 ways layout, it comes equipped with 1/4" wing-nut (butterfly) nozzle holders and heavy-duty ceramic tips, ensuring high wear resistance and a highly uniform application mist.

Out of Stock
€439.00
Tax included
COUPON
- € 8,78
Final price: 430,22
Quantity

Out of stock
Security Policy
Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy
Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments
Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

"T" Frame Style Spray Boom Column 3+3 Ceramic Jets - Code 26848

The professional-grade "T" frame style vertical spray boom column (Product Code: 26848), engineered as a direct structural match adaptable to OEM part number 005010, is a high-precision fluid-dynamic manifold assembly developed for the setup, build, or service of delivery lines on agricultural mist-blowers and vertical canopy sprayers. Thanks to its specialized T-shaped geometric architecture, this manifold secures a perfectly balanced hydraulic flow distribution, yielding specular and completely uniform chemical wetting across both sides of the target crop row.
Design Details and Wing-Nut Jet Engineering
This vertical spray column features a heavy-walled tubular manifold frame with an overall linear extension of 560 mm, sized to absorb structural field vibrations and severe fluid backpressure spikes during intensive spraying cycles. The internal distribution network follows a 3+3 way grid infrastructure (totaling 6 symmetrical delivery points), factory-equipped with adjustable butterfly or wing-nut style nozzle holders featuring a standard 1/4" threaded interface. The technical core of the assembly incorporates technical ceramic orifice discs fitted inside the output housings. Compared to standard brass or plastic components, technical ceramic yields unyielding structural resistance against hydraulic friction under intense pressure loads and completely resists the chemical breakdown triggered by concentrated pesticides, copper solutions, or liquid sulfur mixtures. This material matrix guarantees long-term retention of the pre-set orifice gauge diameter, locking in consistent fluid atomization metrics while preventing accidental over-application or waste of chemical product per hectare.
Technical Specifications
Component Classification T-frame vertical fluid spray column / boom assembly for mist-blower atomizers
Fluid Distribution Layout 3 + 3 independent spray outlets (6 ceramic nozzles total grid)
Manifold Longitudinal Extension 560 mm
Nozzle Holder Interface Profile Adjustable wing-nut / butterfly layout with 1/4" thread connection
Nozzle Material Grade Heavy-duty technical ceramic (high-wear resistance and flow constant stability)
OEM Cross Compliance Adaptable to original equipment factory code: 005010
Product Reference Code 26848
Operational Guidelines and Field Maintenance Advice
  • Rigid Frame Mounting: Anchor the T-chassis securely onto the rear fan cowling of the mist-blower, ensuring the 560 mm horizontal wings mount completely perpendicular to the ground to maintain steady symmetrical spray projection angles.
  • Wing-Nut Jet Orientation: Leverage the swivel joint of the 1/4" butterfly jet bodies to adjust the trajectory profile based on canopy height and leaf-wall density, maximizing chemical penetration while preventing chemical drift or blind spots.
  • Line Rinsing Protocol: Run a clear-water flushing cycle through the line following the application of seasonal treatments or wettable powder compounds. To protect the technical ceramic structure, do not use raw metal wires or sharp metal tools to clear out clogged nozzle orifices.
: 26848
Out of Stock

Fast and safe shipping: each order is carefully packaged to ensure that the product arrives intact and in perfect condition.

We work with reliable couriers to offer an efficient, traceable and punctual service.

You will receive a link to follow the shipment at every stage, until delivery.

We use quality protective materials and, where possible, eco-friendly packaging.

Our priority is that your purchase arrives without surprises, ready to use.
