GRANIT Oval LED Work Light 7070010442 | 20W | 1520 lm | IP69K | Long Range

The GRANIT LED work light 7070010442 is a high-efficiency oval lamp for long-range illumination. Designed to operate in harsh environments (IP6K9K), it features a low power consumption of 20 Watts and delivers an effective luminous flux of 1520 lumens. The robust aluminum housing and plastic lens ensure durability. Mounting is achieved using a stainless steel bracket.

Technical Data

• Part Number: 7070010442 (GRANIT).
• Light Function: Long range illumination.
• Nominal Voltage (V): 12 / 24.
• Voltage (Volt): 10 - 30.
• Power Consumption (W): 20.
• LED Quantity: 8.
• Effective Luminous Flux (lm): 1520.
• Theoretical Luminous Flux (lm): 2240.
• Light Color (K): 5000 - 6500.
• Lamp Type: LED (Bulbs included: Yes).
• Protection Type: IP6K9K.
• Temperature Range (°C): -40 / +50.
• Control Mark: CE / RoHS / ECE R10.
• EMC: CISPR 25 Class 5.

Dimensions and Mounting

• Shape: Oval.
• Dimensions L x H x D (mm): 142 x 90 x 65.
• Frame Size (mm): 90.
• Mounting Method: Stainless steel bracket.
• Connection: Open cable ends (red + / black -).
• Cable Length (mm): 2000.
• Pole Quantity: 2.
• Material: Housing: Aluminum; lens: Plastic material.
