ISO Standard 110° Flat Fan Spray Tip SF 110-01 Orange Kematal Part 25215
The ISO flat fan spray tip SF 110° - 01 is a precision nozzle molded in high chemical-stability acetal resin (Kematal) for extended durability. Featuring the standard ISO Orange color coding and a 110° spray angle, it operates between 1.5 and 7 Bar with a flow rate of 0.28 ÷ 0.61 l/min. It ensures perfectly uniform coverage for herbicide, fungicide, and insecticide applications.
Read more ↓- International Calibration Standard: ISO 01 - Orange (Nominal calibrated orifice scale: Ø 0.5 mm)
- Spray Projection Open Angle: 110°
- Nominal Flow Output Range: 0.28 ÷ 0.61 L/min (Liters per minute discharge constant)
Sconto extra riservato ai clienti registrati
Accedi per sbloccare il codicePrezzo finale con coupon: €0.78
Description
The ISO flat fan spray tip SF 110° - 01 is a precision nozzle molded in high chemical-stability acetal resin (Kematal) for extended durability. Featuring the standard ISO Orange color coding and a 110° spray angle, it operates between 1.5 and 7 Bar with a flow rate of 0.28 ÷ 0.61 l/min. It ensures perfectly uniform coverage for herbicide, fungicide, and insecticide applications.
Specifications
| Component Classification | Standard flat fan crop spraying and weeding nozzle tip (SF Series) |
|---|---|
| International Calibration Standard | ISO 01 - Orange (Nominal calibrated orifice scale: Ø 0.5 mm) |
| Spray Projection Open Angle | 110° |
| Nominal Flow Output Range | 0.28 ÷ 0.61 L/min (Liters per minute discharge constant) |
| Minimum Working Pressure Limit | 1.5 bar |
| Maximum Working Pressure Limit | 7 bar |
| Structural Engineering Metallurgy | High-grade industrial molded acetal copolymer resin (Kematal) |
| Target Chemical Deployment | Pre-emergence and post-emergence herbicide, fungicide, and insecticide applications |
