BLUELINE 377086022912 PTO Shaft Series F22 860mm

377086022912 BLUELINE PTO Drive Shaft Series F22 Lz 860mm for Tractors up to 27HP

Reference : 377086022912

BLUELINE F22 Series PTO Drive Shaft - L 860mm (Code 377086022912)

Hurry! only 2 items left in stock.

€99.00

Tax included

Quantity

Last 2 items

Add to Compare

Add to Wishlist

Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

Guarantee safe checkout

The BLUELINE F22 Series drive shaft (860 mm) is an upgraded transmission component designed for medium-duty agricultural tasks. Featuring reinforced 24 x 61 mm cross kits and a nominal torque of 350 Nm, it provides superior durability compared to lighter series. The Lemon Profile telescopic tubes ensure reliable operation for implements like light flail mowers, hay tedders, and wood saws.

Technical Specifications

Part Number: 377086022912

Series: F22 (Standard Version)

Total Length (Lz): 860 mm

Profile A (Tractor Side): 1 3/8" 6 Splines

Profile B (Implement Side): 1 3/8" 6 Splines

Cross Kit Dim. (Profile A/B): 24 x 61 mm

Locking System: Push-button / Push-button (G3/G4 Coupling)

Tube Profile: Lemon Profile

Performance Data

Power at 540 rpm: Up to 27 HP (20 kW)

Power at 1000 rpm: Up to 40 HP (30 kW)

Nominal Torque (540 rpm): 350 Nm

Nominal Torque (1000 rpm): 285 Nm

Operating instructions are included. To ensure long service life, regular maintenance of the universal joints and lubrication of the lemon profile telescopic tubes is essential.
