GRANIT LED Work Light 11351702 | 36W | 1800 lm | Spot Beam 30° | IP67

The GRANIT 11351702 LED work light is a 36 W angular unit optimized for concentrated illumination (Spot) with a 30° angle. It provides an effective luminous flux of 1800 lumens from 12 LEDs. It features an aluminum construction, IP67 protection rating, and excellent electromagnetic compatibility (EMC CISPR 25 Class 1).

Functional Specifications and Performance

• Light Function: Spot, 30°.
• Effective Luminous Flux: 1800 lumens (lm).
• Theoretical Luminous Flux: 2880 lumens (lm).
• Luminous Flux (Generic): 2800 lumens (lm).
• Power (Watts): 36.
• LED Quantity: 12.
• Lamp Type: 3W high-power LED.
• Rated Voltage: 12 / 24 Volts (V).
• Voltage (Volts): 10 - 30.
• Light Tone: 6300 Kelvin (K).
• Thermal Range: -20°C / +40°C.
• EMC: CISPR 25 class 1.

Technical and Structural Data

• Part Number: 11351702.
• Shape: Angular.
• Dimensions W x H x D: 98 x 76 x 82 mm.
• Width: 98 mm.
• Height: 76 mm.
• Depth: 82 mm.
• Material: Aluminium.
• Body Color: black.
• Bulbs Included: Yes.
• Mounting: Mounting.
• Protection Type: IP67.
• Connection: Cable.
• Cable Length: 350 mm.
• Certification Mark: ECE R10 / CE UKCA / ROHS.
