3771210B112 BLUELINE PTO Drive Shaft Series B1 Lz 1210mm for Tractors up to 16HP
3771210B112 BLUELINE PTO Drive Shaft Series B1 Lz 1210mm for Tractors up to 16HP
iPhotos are indicative: the product may differ in some details. Refer to the specifications.
BluelineRef.

3771210B112 BLUELINE PTO Drive Shaft Series B1 Lz 1210mm for Tractors up to 16HP

BLUELINE B1 Series PTO Drive Shaft - L 1210mm (Code 3771210B112)

€109.90VAT incl.
Coupon -€2.20 -2% sul carrello

Sconto extra riservato ai clienti registrati

Accedi per sbloccare il codice

Prezzo finale con coupon: €107.70

Not sure it fits?Message us with your tractor model
WhatsApp
Secure paymentsEasy returnsFree shipping over €30 + VAT

Description

The BLUELINE B1 Series drive shaft (1210 mm) is a reliable power transmission solution for agricultural implements requiring an extra-long reach. Built with the "Italian System" tube profile, this standard version features push-button locks on both ends, providing efficient power transfer and ease of use for light-duty tasks.

Technical Specifications

Part Number: 3771210B112

Series: B1 (Standard Version)

Total Length (Lz): 1210 mm

Profile A (Tractor Side): 1 3/8" 6 Splines

Profile B (Implement Side): 1 3/8" 6 Splines

Cross Kit Dim. (Profile A): 22 x 54.8 mm

Cross Kit Dim. (Profile B): 22 x 54.8 mm

Locking System: Push-button / Push-button (P1/P2)

Tube Profile: Italian System

Performance Data

Power at 540 rpm: Up to 16 HP (12 kW)

Power at 1000 rpm: Up to 24 HP (18 kW)

Nominal Torque (540 rpm): 210 Nm

Nominal Torque (1000 rpm): 170 Nm

Operating and safety instructions are included. Always ensure the protective shield is in good condition and properly chained.
