3771010B234 BLUELINE PTO Drive Shaft Series B2 Lz 1010mm for Tractors up to 27HP

BLUELINE B2 Series PTO Drive Shaft - L 1010mm (Code 3771010B234)

Not sure it fits?Message us with your tractor model

Secure paymentsEasy returnsFree shipping over €30 + VAT

Description

The BLUELINE B2 Series drive shaft (1010 mm) is engineered for higher durability in medium-duty agricultural applications. With 24x61 mm cross kits and an "Italian System" tube profile, this standard shaft offers superior torque capacity (up to 350 Nm at 540 rpm) and secure coupling via push-button locks on both ends.

Technical Specifications

Part Number: 3771010B234

Series: B2 (Standard Version)

Total Length (Lz): 1010 mm

Profile A (Tractor Side): 1 3/8" 6 Splines

Profile B (Implement Side): 1 3/8" 6 Splines

Cross Kit Dim. (Profile A/B): 24 x 61 mm

Locking System: Push-button / Push-button (P3/P4 Coupling)

Tube Profile: Italian System

Performance Data

Power at 540 rpm: Up to 27 HP (20 kW)

Power at 1000 rpm: Up to 40 HP (30 kW)

Nominal Torque (540 rpm): 350 Nm

Nominal Torque (1000 rpm): 285 Nm

Usage instructions are included. For shafts exceeding 1 meter, always ensure the safety chains are properly attached to prevent the shield from rotating.
