LED Work Light 7070010446 | 10W | 12/24V | Close Range Illumination | IP6K9K
ROUND LED WORK LIGHT Close-Range Illumination IP6K9K Part No. 7070010446
Read more ↓€33.90VAT incl.
⚡ Limited-time deal
00days
:00hrs
:00min
:00sec
Coupon
-€0.68
-2% sul carrello
Sconto extra riservato ai clienti registrati
Accedi per sbloccare il codicePrezzo finale con coupon: €33.22
Not sure it fits?Message us with your tractor model
WhatsAppSecure paymentsEasy returnsFree shipping over €30 + VAT
Description
A compact, high-efficiency LED work lamp for close-range or short-distance area illumination. Featuring a round shape, high resistance to dust and high-pressure water jets (IP6K9K), and compatibility with both 12V and 24V vehicles.
Technical Details and Performance
Part Number: 7070010446
Light Function: Close-Range Illumination (Spot/Flood)
Nominal Voltage (V): 12 / 24
Operating Voltage (V): 10 - 30
Lamp Type: LED (1 unit)
Power Consumption (W): 10
Effective Luminous Flux (lm): 743
Theoretical Luminous Flux (lm): 900
Light Color (K): 5000 - 6500 (Cool White)
Construction and Mounting
Shape: Round
Dimensions W x H x D (mm): Ø 62 x 75 (Diameter x Depth)
Structural Size (mm): 75 (Presumed total height with bracket)
Housing Material: Aluminum
Lens Material: Plastic Material
Mounting Method: Stainless Steel Bracket
Connection: Open Cable Ends (Red + / Black -)
Cable Length (mm): 2000 (2 meters)
Protection Type: IP6K9K (Maximum protection against dust and high-pressure/temperature water jets)
Temperature Range (°C): -40 / +50
Approvals
Testing Mark: CE / RoHS / ECE R10
EMC: Radio interference suppression according to ECE R10
Key Advantages
- **Compact and Powerful:** High luminous flux (743 effective lm) in a small design (Ø 62 mm).
- **Very High Protection:** IP6K9K rating, ideal for extreme work environments (agricultural machinery, construction).
- **Universal Compatibility:** 12V and 24V operation (10V-30V Range).
- **EMC Compliance:** Radio interference suppression to avoid disrupting onboard electronics.
